Product Description
Panel Thickness |
2-6mm |
Aluminium skin |
0.02-0.50mm |
Core |
Unbroekn core,Fireproof core |
Coated |
PVDF;PE |
Standard Panel Size |
1220*2440*4mm |
Non-standard Panel Width |
1000mm;1220mm;1250mm;1350mm;1500mm; |
Non-standard Panel Length |
Depends on clients requirement |
Packaging & Shipping
1) 20 foot container: 2mm panel-6000M2, 3mm panel-5000M2, 4mm panel-4000M2, 5mm panel-3000M2.
2) 40 foot container:2mm panel-8000M2, 3mm panel-7000M2, 4mm panel-6000M2, 5mm panel-5000M2.
Material
1) Top: aluminum alloy(3003) coated with Fluorin carbon resin (PVDF) or Polyester resin (PE) roasting painting.
2) Core:non-toxic polyethylene or fireproof material(B1).
3) Back:aluminium alloy sheet coated with polyester resin painting.
4) Surface finish: PVDF / PET coated,brushed finish, mirror finish, wooden faced,marble faceed ,nano paintingect.
5) Surface coating thickness :25~30 μm 70% KYNAR 500 PVDF or PET.
Feature
1)Super werther resistance
2)Light weight easy to process
3)Excellent fire resistance
4)Excellent impact strength
5)Uniform and colorful coating
6)Easy maintenance...and so on
Certification
According to GB/T17748-1999 standard and ISO9001,SGS,CE etc.
2. STANDARD
|
A) Front : aluminium alloy sheet coated with Pleochromatic PVDF paint on surface B) Core: nontox low density polyethylene C) Back: aluminium alloy sheet coated with polyester resin painting D) Surface coating thickness: 32μ±1μ E) Aluminium alloy: 3003 H24 F) Sheet thickness: 0.3mm,0.4mm,0.5mm |
|
3. FEATURES
A) Light weight,flat surface and high strength
B) Excellent heat insulation ,sound insulation,fire-resistance,acid-resistance,alkali-resistance,weatherproofness and non-resonance
C) Various uniform colors
D) Rbright ,elegan and magnificent,fit for various designs
E) Kynar 5000 PVDF resin feature strong chemical resistance,unique colors can be easily maintained
4. APPLICATIONS
A) May be widly used in gallaies,exhibition,saloons,stores,offices,banks,hotels,restaurants and apartments
B) An ideal decorative materials for buildings
C) An ideal outer and inner walls
D) Kitchen cabinees,billboards,signboards,tunnels,subway,interiors
E) Cellings,eaves,galleries,balconies,partitions,interior decorations
F) Telephone tooths,vehicle bodies,yachts,industrial usage etc.
