Home > Consumer Electronics > Display & Accessories > LCD Module > 2.2 Inch STN Character Cog Lcd Module 16x2
US$ 1 - 20
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Huayuan
Type:
COG
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
16x2 Lcd Display, Blue STN COG Character Lcd ModuleUS$ 1 - 20MOQ: 1 Piece -
2.4 Inch STN COB 16x4 Character Lcd ModuleUS$ 1 - 50MOQ: 1 Piece
-
16x2 Lcd Character Module With LED BlacklightUS$ 1 - 50MOQ: 1 Piece
-
16x4 Character 2.4 Inch Lcd ModuleUS$ 1 - 50MOQ: 1 Piece
-
16X2 Dots Matrix Cob Character LCD Screen Module( GH1602-2201)US$ 1 - 10MOQ: 100 Pieces
Place of Origin
Hunan, China
Brand Name
Huayuan
Type
COG
Specifications
character cog lcd moduleRohs compliance available
OEM Product Design / Production
customized product acceptable
The module datasheet
| 2.2 inch STN character cog lcd module 16x2 | |
| Construction | COG |
| Display Type | STN,Negative or Positive ,Transmissive |
| Operating Voltage (VDD) | 3.3V,5V |
| Backlight Voltage(VBL) | 3.3V,5V |
| Operating Temperature (degree Celsius) | -20~70 |
| Storage Temperature (degree Celsius) | -30~80 |
| Viewing Direction | 06:00 |
| Dot Matrix | 16*2 |
| Viewing Area | 64.50*16.40 |
| Active Area | 56.05*11.55 |
| Outline Dimension | 80.00*36.00*12.00 |
| Controller | ST7066U |
| Backlight | LED,Y-G |
The Layout Drawing
