ADSL2+ Modem Router

Name: ADSL2+ Modem Router
Brand: tp link
SKU: 131884151
Availability: InStock

Shenzhen Tengqingfeng Technology Co., Ltd.

US$ 31 - 33 MOQ: 1 Piece

Key Specifications

Products Status:

Stock

Type:

Wireless

Application:

Enterprise

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Wireless

Application Enterprise

Function QoS, VPN

LAN Ports 3

WAN Ports 1

Certification CE

Brand Name tp link

Model Number TD-8840T

Place of Origin Guangdong, China

ADSL2+ Modem Router TD-8840T

Provide Internet access via ADSL Service and create a wired sharing network, all with one product
Works with the latest ADSL standards: up to 24Mbps downstream superior performance
Live Parental Controls allow parents or administrators to establish restricted access policies for children or staff
IP QoS features for improved bandwidth control across the network

HARDWARE FEATURES
Interface	4 10/100Mbps RJ45 Ports 1 RJ11 Port
Button	1 Power On/Off Switch
External Power Supply	9VDC/0.6A
IEEE Standards	IEEE 802.3, 802.3u
ADSL Standards	Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1 , ITU-T G.996.1, ITU-T G.997.1, ITU-T K.2.1
ADSL2 Standards	ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4 (G.lite.bis)
ADSL2+ Standards	ITU-T G.992.5
Dimensions ( W x D x H )	6.54.31.1 in.(16510828mm)

SOFTWARE FEATURES
Quality of Service	QoS Remarking based on IPP/ToS, DSCP and 802.1p
Port Forwarding	Virtual server, DMZ, ACL(Access Control List)
VPN Pass-Through	PPTP, L2TP, IPSec Pass-through
ATM/PPP Protocols	ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), PVC - Up to 8 PVCs,
Advanced Features	Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt; Dynamic Host Configuration Protocol (DHCP), DHCP relay; Network Address Translation (NAT); Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS IGMP Multicast, UPnP
Security	NAT Firewall, MAC /IP /Application/URL Filtering
Management	Web Based Configuration(HTTP), Remote management, Telnet management, SNMP v1/2c, SNMP over EOC, Web Based Firmware Upgrade, Diagnostic Tools

OTHERS
Certification	CE, FCC, RoHS
Package Contents	TD-8840T External Splitter RJ-11 Telephone Cable RJ-45 Ethernet Cable Quick Installation Guide Resource CD Power Adapter
System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
