Help CenterAluminum Pcb/pcba Board
Related Products
Specifications
1.best quality, best price2.skilled operation techniques,can do SMD0402
3.fast delivery
| Place of Origin | Guangdong, China (Mainland) |
| Brand Name | aluminum pcb/pcba board |
| Model Number | YQ-WZ0023 |
| Base Material | Aluminum base |
| Copper Thickness | 1OZ |
| Board Thickness | 1.6mm |
| Min. Hole Size | 0.2mm |
| Min. Line Width | 3mil |
| Min. Line Spacing | 3mil |
| Surface Finishing | HASL Lead Free |
| Solder Mask | white oil |
| PCBA Production | OEM/ODM PCB Assembly Service |
| Advantage | Components with One-Stop Service |
| Board finished thickness | 0.4mm-4.0mm |
| Max.finished board size | 410*360mm |
| Min.Line width | 3mil |
Detailed Terms for Pcb and pcba Assembly
1)Technical requirement:
1. Professional Surface-mounting and Through-hole soldering Technology
2. Various sizes like precision0402, 0603, 0805, 1210 and 2512 components SMT technology
3.ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4.PCB Assembly With CE,FCC,Rohs Approval
5.Nitrogen gas reflow soldering technology for SMT.
6.High Standard SMT&Solder Assembly Line
7.High density interconnected board placement technology capacity.
Quote requirement:
1.Gerber files of the bare PC board
2.BOM file (Components List): manufacturer’s part number, type of part, packaging type, component
locations and quantity
3.Dimensional specification for non-standard components
4.Assembly drawing
5.Final test procedures (if applicable)
6.in order to shorten the lead time, please advise us alternative parts (same specifications but
different brand name)
7.Estimated order quantity
8.If possible, please send prototype/sample board/photo to us for further reference
.We also offer:
1.Contract Manufacturing
2.Engineering Services
3.PCB Design & Assembly
4.Product Design
5.Prototyping
.applications of our products:
1.Computers and relevant products: Movable power board, U Disk, network interface, panel
computer, cameral, wire-less mouse.
2.Home appliance: smart projector/digital cameral, high-frequency board. Recorder and repeater
board, auto audio equipment main board and control board.
3.Wire-less communication: mobile board,. GPS/ direction record board, wireless telephone main
board, intercom main board.
4.LED Lighting: LED drive power, LED light panel, LED light belt.
5.We have been specializing in the production of control units for commercial equipment such as
industrial measuring and testing equipment, monitory and inspection systems, computers, home
appliance such as air conditioners,refrigerators, solar-power systems, water-heat and automotives
