Specifications
1.biaxial geogrid & uniaxial geogrid2.reinforcement materials for construction,etc.
3.save cost
tect the culver
Geogrid Machine
My company manufacture geogrid production line equipment is determined by more than one combination of ultrasonic plastic welding machine adopts imported PLC control has the following advanced features:
1, touch-screen display and parameter setting, imported piezoelectric ceramic transducer, the output strength and stability.
2, color display touch-screen control panel.
3, all-Chinese menu, with multi-language you set, easy to use.
4 levels of adjustable mold design, mold fast and easy adjustment.
5, the new power amplifier circuit, power is more robust, more durable transducers,
6, frequency automatic tracking, a variety of parameter settings. High degree of automation in the domestic production of similar products in the leading position.
Earthwork Grid Production Line Model Specification Table
Geogrid welding head station |
HJM-12-3 |
HJM-16-4 |
HJM-24-6 |
HJM-32-8 |
|||
Welding digits |
12 unit |
16 unit |
24 unit |
32 unit |
|||
Maximum output power |
31.2KW |
41.6.4KW |
62.4KW |
83.2KW |
|||
Ultrasonic output power |
15.6KW |
20.8KW |
31.2KW |
41.6KW |
|||
Equipment Dimensions |
4.5*1.76*2.46 |
5.5*1.76*2.46 |
7.5*1.1.76*2.46 |
9.5*1.76*2.46 |
|||
Weight |
3.5TONS |
4.8TONGS |
5.7TONS |
7.5TONS |
|||
Rated input voltage |
AC380V N 50-60HZ |
||||||
Rated input pressure |
0.8~0.10MPa |
||||||
Air pressure vessel |
≥2.5~3.0/min |
||||||
Air Flow |
1.5~2.0M3 |
2.5~3.0M3 |
|||||
Transverse weld pitch |
50mm-80mm-125mm-150mm-200mm--3000 |
||||||
Longitudinal distance between welding points, |
50mm-150mm |
||||||
Geogrid width of the welding machine |
3m |
4m |
6m |
8m |
|||
24 hours a day production |
3500SQM |
4500 SQM |
6500SQM |
8500SQM |
|||
