Help CenterPressure Feed Spray Gun W-200PT
Related Products
Specifications
Air inlet: G1/4 . Size: 0,8 - 2,0mm Material Connection: G3/8Pressure feed spray gun W-200PT
Rapid work is ensured by the particularly wide fan and the high material flow rates. The slightly higher air cap pressure, compared to HVLP guns, adds the feeling of working with a conventional high pressure gun. Thus, switching to VOC conforming gun is made easy.
*Finest atomization and a top-class finish are ensured by optimized high pressure. Even with the latest generation of High Solid materials, excellent atomization quality is achieved.
*Due to the higher air cap pressure, compared to HVLP guns, less compressed air is required for atomization.
*Highest profitability – LVMP technology ensures transfer efficiencies considerably above 65 % required by VOC legislation. Therefore, this pressure-fed high performance gun not only helps to protect the environment, but also saves lots of expensive paint (approx. 30 % compared to a conventional high pressure gun).
*Air circulation principle provides an especially homogeneous and soft fan.
*100 % hand checked nozzle sets ensure the constantly high quality - for complete guns as well as spare nozzle sets.
The durable air caps are made of brass (not of aluminum), therefore ensuring a long life time - a factor particularly important in industrial use.
*Nozzle sets ranging from 0.8 to 2.0mm mean a wide field of application.
*The gun can be adapted without great effort to existing work stations.
*Excellent handling - the short gun body, the extremely low weight and
the optimum balance ensure the gun "fits like a glove".
*Suitable for water-borne materials - paint needle and nozzle are made of
stainless steel, and the nickel-plated gun body has been refined with a
special coating.
*Self-adjusting air and material packings with long life times considerably
reduce servicing efforts.
*The carefully polished nickel-plated gun surface and the quick change system reduce cleaning efforts as well.
*Naturally, the gun is equipped with a material flow control, a round / flat
spray control and an air micrometer.
*Please also see our broad range of material feed systems, such as paint pressure tanks, diaphragm and piston pumps.
Technical Parameters:
Air consumption: 15,2 cfm
Recommended inlet pressure: 2,5 bar (36,3 psi)
Maximum operating temperature: 50°C
Maximum operating overpressure: 10 bar (145 psi)
Air inlet: G1/4 .
Size: 0,8 - 2,0mm
Material Connection: G3/8
