barcode scanner bluetooth wifi smart phone
| General Specifications | |
| Operation System | Google Android 5.1.1 |
| CPU | Qualcomm 8909, 1.2Ghz, Quad Core |
| Memory | 1GB RAM, 8GB ROM |
| Extension Storage | T-Flash/Micro SD Card, up to 32GB |
| Networks | WCDMA 850/2100Mhz |
| CDMA 800Mhz | |
| GSM 850/900/1800/1900Mhz | |
| 4G LTE | |
| Display | 4.3” HD LCD, Capacitive Touch Screen, Resolution 800*480 |
| Camera | Front 2.0M and Rear 8.0M Pixels, Auto Focus with Flash |
| Wireless Communication | |
| GPS | Integrated, 10m |
| WiFi | IEEE 802.11b/g/n |
| Bluetooth | BT 4.0 with A2DP |
| Optional Parts | |
| UHF RFID | ISO 18000-6C, 0-2m |
| NFC Scanner | Supported |
| Contact IC Card | Compatible with ISO 7816-3 and EMV 4.2 |
| Contactless IC Card | ISO/IEC 14443 Type A/B |
| Fingerprint Reader | Capacitive Sensor, 508 DPI |
| Barcode Scanner (1D) | UPC/EAN, Bookland EAN, UCC Coupon Code, ISSN EAN, Code 128, GS1-128, ISBT 128, Code 39, Trioptic Code 39, Code 32, Code 93, Code 11, Interleaved 2of5, Discrete 2of5, Codabar, MSI, Chinese 2of5, Matrix 2of5, Inverse 1D, Korean 3of5, GS1 DataBar, Composite Codes |
| Barcode Scanner (2D) | PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, Micro QR, QR Inverse, Aztec, Aztec Inverse, US Postnet, US Planet, US Postal, Japan Postal, Australian Postal, Netherlands KIX Code, USPS 4CB/One Code/Intelligent Mail, UPU FICS Postal |
| Physical Layer Parameter | |
| Dimensions | 156.8*79.5*22.2mm |
| Weight | 400g |
| PSAM | 2 slots |
| Battery | 3.7V, 3000mAh |
| USB | Mini-USB 10pin |
| Charger | DC 5.5V 1.2A |
| Headphone | Supported, 3.5mm |
| Speaker | supported |
| Ruggedness | IP65, waterproof, dustproof, shockproof |
| Reliability | MTBF no less than 10000 hours |
| Temperature | -20℃~+70℃ |
Corewise is a leading high-tech enterprise specialized in manufacturing various terminals around smart phones integrated with fingerprint sensors, RFID writers/readers (13.56 MHz for proximity or 840-960 MHz for long range), barcode scanners and thermal printers. These seemingly premature products are hardware ready for further developments to fit any needs using technologies of biometric fingerprint imaging/capturing, RFID & barcode scanning.
Our devices are semi-finished product, which requests further development resorting to our SDK on basis of its hardware.
Normally the Buyer shall have technical development capability and technical support capability. Of course we will provide
online help/support if required.
We provide free SDK ,DEMO and the application development guide and development environment introduction,
meanwhile,we will provide technical support in your development process.
(You are also welcome to commission this development job to us,we will charge it according to the development period)
After - Sales Service:
1. One-year warranty:
If with nonhuman factors quality problems in two years, Corewise assures you the repair, maintenance or replacement for free.
If with damages caused by users, you need to purchase the accessories for the repair, maintenance or replacement.
If you pay 8% more per piece, with the warranty of one-year more.
2. After the order, Corewise provides you 2% of the accessories in extra, you can select the type and quantity according to the requirements.
3. Corewise and the client undertake respectively 50% of the freight, you are in charge of the one back to China, and we, of the one delivered to you.
4. Corewise ensures to provide the same product during the continuous three years, with the same accessories. But the mainboard or the chip might be changed due to the upgrade process.
FAQ:
1.Q:Are you manufacturer?
A:Yes.Our company headquarters is located in Nanjing of China, factory in shenzhen.
2.Q:Can you provide application software for the hardware?
A:We provide free SDK and User manual of all API to support your development or programming.
3.Q:What is the warranty?
A:The warranty time is 1 year without man-made damage.
3.Q:Does the device have the language default as English?
A:Of course, our device supports multi-language such as English,Spanish, Portuguese ,French, German,Polish,Japanese, Russian and so on.
4.Q:Can your device install the Android Apps that our customers provide?
A:No problem. Just send us your Apps which you need to get the liscense of the apps and then our Engineers can do that for you.
If you have any other question about our products,please don’t hesitate to contact us.We will be more than happy to serve you.
