Specifications
* High efficiency and effectiveness.* High performance security system.
* Available in mobile or stationary options.
NSH LV series oil purifier are suitable especially for purifying and restoring hydraulic oil, machine oil, coolant oil and various other lubrication oil. The most breakdown of machinery which has lubrication oil system results from contaminated lubrication in which has water, gas, impurities etc. LV series can rapidly remove water, gas, particulate matters and impurities from lubrication oil and improve properties of lubricating oil so as to greatly extend lifetime of machinery which has lubrication system.
Technical Specification of LV-30
Item |
Unit |
LV-30 |
|
Flow Rate |
L/H |
1800 |
|
Vacuum Range |
MPa |
-0.065~~ -0.096 |
|
Working Pressure |
MPa |
≤ 0.4 |
|
Water Ratio |
PPm |
≤ 100 |
|
Impurity size |
µm |
≤ 5 |
|
Clearness |
NAS(1638) |
≤6 |
|
Temperature Range |
°C |
40—80 |
|
Power Supply |
V |
~50Hz 380V (or as needed) |
|
Working Noise |
dB |
≤ 70 |
|
Heating Power |
Kw |
30 |
|
Total Power |
Kw |
39 |
|
Inlet (Outlet) Diameter |
Mm |
DN25 |
|
Net Weight |
Kg |
600 |
|
Size |
length |
Mm |
1600 |
width |
Mm |
1100 |
|
height |
Mm |
1550 |
|
