Specifications
Powder Packing Machine1.PLC controller, auger as filler
2.Filling capacity: Max.1000g
3.OEM acceptable
4.CE certificate
Model: DXDF-350 Automatic Powder Packing Machine
Application:
The machine is designed and manufactured specially for packing powdery and soft pouch in medical, food and chemical industries etc. Such as pepper, coffee, medical powder, pollen, milk powder, tea powder, flour, bean flour etc.
You are welcomed to send us the products and packing film for testing our machine, we will show you video and sample. Just email me for our address.
Technical Data:
| Model | DXDF-350 | ||
| Power supply | 220V, 50Hz, single phase | ||
| Power | 1.9KW | ||
| Speed | 15-40bags/min (depend on product property and filling range) | ||
| Filling capacity | Max.1000 g | ||
| Film width | Max. 400 mm | ||
| Bag size | Length:50-300mm, Width:40-180mm | ||
| Style of bag sealing | back sealing (pillow bag) | ||
| Measuring method | Screw auger | ||
| N.W./G.W. | Approx. 420kg/520kg | ||
| Dimension | L1450*W1000*H2100mm | ||
Why our machine better than other similar machines?
1. Control system: The operation facility is controlled by Mitsubishi PLC, all functions are displayed on English digital screen.
2. Raw material: All stainless steel cover meets to international GMP standard.
3. Dosing system: Screw auger.
4. Photocell controller is easy to fix location, step motor to pull the packing film.
5. Adjustment: Automatic adjustment of pouch size and filling range, no need to change any machine parts.
6. Intelligent temperature controller is used in sealing and the error of sealing temperature is at plus or minus 2 degrees.
7. Outstanding sealing system: Air cylinder and high-powered heat sealing structure ensure sealing of the bag firm, neat and with good airtightness.
8. OEM is acceptable and the machine that has special bag-size or requirements can be designed and produced specially.
9. Ribbon code printer, elevator, conveyor are as an option.
There is more information in our databases, welcome to inquire us anytime! We will reply you within 24 hours.
Packing materials: Several kinds of heat-seal lamination, such as PET/Plated AL/PE, PET/PE,Nylon etc.
How to use: Please see the User Manual to see how to set up and use this machine.
Machine picture:
Machine Parts:
Sample bags:
Packaging:
