Help CenterMC-750H Optical Microscope With Camera
Related Products
-
MC-750H Optical Inspection MicroscopeUS$ 1 - 1,200MOQ: 1 Set -
MC-730 400x Fiber Optic MicroscopeUS$ 20 - 120MOQ: 1 Set
-
MC-730 400x Optical Inspection MicroscopeUS$ 20 - 120MOQ: 1 Set
-
MC-730 400x Fiber Optical Inspection MicroscopeUS$ 20 - 120MOQ: 1 Set
-
MC-750E Fiber Optic MicroscopeUS$ 400 - 800MOQ: 1 Set
Specifications
1. Optical Microscope With Camera2 High resolution magnification
3. Multi connectors available
4. 12V rechargeable batte
MC-750H Optical Microscope With Camera is used to inspect end-face of fibers and check the optic connectivity. It magnifies fibers of 125um diameter 200 times, and clear to see the end-face of various connectors.
Not only portable, easily in-hand,MC-750H Optical Microscope With Camera is also multi-functional. It can detect simplex and ribbon fiber ends located in both male and female connectors, as well as other fiber units.Also, working comfortably is it’s another feature. Eliminating the need to finding solutions for hard-to-reach areas inspection, MC-750H Optical Microscope With Camera can detect connectors such as FC,SC ,ST,E2000,LC,MU and TOSA,ROSA optical components,SFP,QSFP and XFP optical module, providing you a completely convenience for checking.
With 12v rechargable battery,it supports 6 hours continous work.
Features
- Optical Microscope With Camera
- High-resolution magnification
- Male,female connector inspection
- TOSA/ROSA optical componnets inspection
- SFP,QSFP,XFP optical module inspection
- Multi connectors available
- Easy operation
Specification
Model |
MC-750H |
Magnification |
200× or 400x |
AV output |
PAL |
Display Screen |
3.5” TFT220KLCD |
Power Consumption (w) |
3 |
Working Temperature (°C) |
-10—+50 |
Storage Temperature (°C) |
-20—+60 |
Power |
12V recharge battery or DC 12V, W/adaptor |
Working Time (h) |
6 |
Monitor Dimension (mm) |
205×94×25 |
Microscope Dimension (mm) |
23x160 |
Standard accessory
1. Probe
2. LCD Screen
3. Standard Tips: 1) 2.5mm-M 2)1.25mm-M 3)FC/PC-F 4)SC/PC-F 5)ST/PC-F 6) LC/PC-F
4. Battery charger
5. USB-BNC cable
6. Manual
7. Carrying bag
1. Standard warranty is 12 months.
2. Extended warranty is available with addtional and reasonable cost .
