Specifications
1. LED Light Source2. -7dB tunable range
3. FC/SC/ST interchangeable connector
4. Removable sleeve
This LS6206 LED Light Source is designed to work together PM6106 series optical power meter.
When working with PM6106 series optical power meter, LS6206 LED Light Source can realize the auto wavelength identification and auto frequency identification.
The output power of LS6206 LED Light Source is adjustable, which provides better assistance to customers’ work.
With 3 alkaline battery,LS6206 series LED Light Source can continously work 45 hours.
Features
- LED Light Source
- Max 4 wavelength output in one unit
7dB output power adjustable range
Tone generation, 270HZ, 330HZ, 1kHZ and 2kHZ
- Intelligent backlight control which can be adjusted manually or automatically according to ambient brightness
- Up to 45 working hours
- External AC adapter
- Low battery indication
Specification
Model | LS6206 | |
Operating Wavelength (nm) | 850/1300 or 1310/1550 | 850/1300/1310/1550 or 1310/1490/1550/1625 |
Emitter | FP-LD | |
Connector | Interchangeable FC/SC/ST | |
Output Power (dBm) | -5~-12 | |
Adjustable Output Power Step (dBm) | <0.5 | |
Adjustable Output Power Range (dB) | ≥5 | |
Stability (dB, 30min@20°C) | 0.15 | |
Modulation (Hz) | CW, 270,330,1K,2K | |
Battery | AA (3pcs) | |
Power Adapter (V) | 8.4 | |
Operating Time (h) | 45 | |
Operation Temperature (°C) | -10~+60 | |
Storage Temperature (°C) | -25~+70 | |
Dimension (mm) | 175*90*44.5 | |
Weight (g) | 263(including batteries) | |
Standard Accessories
1) Main Unit
2) Cleaning Stick
3) Battery
4) Carrying Bag
5) Manual
6) Power Adapter
Ordering Information
LS6206-L-C-W-PA | |||
Laser (L) | Connector Type (C) | Wavelength (W) | Power Adapter (PA) |
L1: LD (for SM) L2: LED (50/125um for MM) L2: LED (62.5/125um for MM)
| C1: Standard FC/SC/ST/PC C2: interchangeable FC/SC/ST/APC
| W1: 1310/1550nm W2: 850/1300nm W3: 1310/1490/1550nm W4: 1310/1550/1625nm W5: 850/1300/1310/1550nm W6: 1310/1490/1550/1625nm
| PA1: USA power adapter PA2: EU power adapter
|
1) LED Light Source + cleaning cotton stick+manual+battery+carrying pouch+carton box
1) The standard warranty is 18 months.
2) The extended warranty is also available with reasonable and additional cost.
3) Customized products are also available as per your specific request.
