Scorpion SII-4020-420KV Motor for Aeroplane
US$ 1 - 139.99
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Use:
Other, Vehicles & Remote Control Toys
Place of Origin:
Guangdong, China
Brand Name:
Scorpion
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Scorpion SII-3026-1190KV (V2) Motor for AeroplaneUS$ 1 - 124.99MOQ: 10 Pieces -
Scorpion SII-3026-890KV (V2) Motor for AeroplaneUS$ 1 - 124.99MOQ: 10 Pieces
-
Scorpion SII-3026-710KV (V2) Motor for AeroplaneUS$ 1 - 124.99MOQ: 10 Pieces
-
Scorpion SII-3020-1110KV (V2) Motor for AeroplaneUS$ 1 - 109.99MOQ: 10 Pieces
-
Scorpion SII-3020-890KV (V2) Motor for AeroplaneUS$ 1 - 109.99MOQ: 10 Pieces
Use
Other, Vehicles & Remote Control Toys
Place of Origin
Guangdong, China
Brand Name
Scorpion
Model Number
SII-4020-420KV
Scorpion SII-4020-420KV Motor for Aeroplane
Technical Drawing:
Data Chart:
Specifications:
| Stator Diameter | 40.0 mm (1.575 in) |
| Stator Thickness | 20.0 mm (0.787 in) |
| No. of Stator Arms | 12 |
| Magnet Poles | 14 |
| Motor Wind | 17 Turn Delta |
| Motor Wire | 17-Strand 0.25mm |
| Motor Kv | 420 RPM / Volt |
| No-Load Current (Io) @ 10 v | 0.91 Amps |
| Motor Resistance (Rm) | 0.032 Ohms |
| Max Continuous Current | 70 Amps |
| Max Continuous Power | 1500 Watts |
| Weight | 288 Grams (10.16 oz) |
| Outside Diameter | 48.9 mm (1.925 in) |
| Shaft Diameter | 5.98 mm (0.235 in) |
| Body Length | 46.15 mm (1.816 in) |
| Overall Shaft Length | 78.40 mm (3.086 in) |
| Max Lipo Cell | 6s |
| Motor Timing | 5deg |
| Drive Frequency | 8kHz |
Weight including packaging:
- 672g
Company Workshop:
Packing:
Certificate:
