Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897

Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897 thumbnail-1
Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897 thumbnail-2
Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897 thumbnail-3
Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897 photo-1
Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897 photo-2
Intel Haswell I3/I5/I7 Dual Core NUC Mini Computer NIS-H897 photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2006
Factory Size:
1,000-3,000 square meters
Contact Supplier Request Quote Chat Now
Shenzhen Yacoo Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Processor  CPU Intel® HaswellTM /BrodwellTM U-series CPU (dual core)compatible with I3/I5/I7
Chipset  Intel® Haswell
BIOS  SPI BIOS, CMOS 480mah
RAM  Architecture  DDR3 MAX 1666 MT/s
Capacity  MAX 16GB
Socket  SODIMM
Display  Graphic Controller  Intel® HD4000 Graphic media accelerator
LVDS  Dual channel 24 bit LVDS
Max. resolution: 1920 * 1200
HDMI  HDMI 1.4
Max. resolution: 4096 * 2304 24Hz
Display Port  DISPLAY PORT++ 1.2
Max. resolution: 3200 * 2000 60Hz
Display  HDMI+DP+LVDS, Synchronous or asynchronous display
LAN  Controller  LAN 1: RTL8111E GbE
LAN 2: RTL8111E GbE
Audio  Controller  Realtek HD ALC662 audio decoder(Right&left Channel + Mic)
Super I/O  Controller  NT6102
H/W Monitor  Watch Dog Timer 0-255 sec., provide watch dog routine
Thermal  DC +12V Fan, support SMART FAN and system temp. detection
TPM  Controller  N/A
I/O  USB  6*USB 3.0 PORT
Serial Port  2*TTL COM
Expansion Bus Mini-PCIe 1* full size Mini-PCIe(support PCIe & USB devices)(support M-SATA for storage only)
USIM 1 * standard 3G UIM socket
Storage  Laptop SATA  7+15Pin, adopt onboard heightened connecto
Power  Power Type  DC9-19V extended voltage dynamic input,support reverse power protection
Power Consumption  Typical Power: 15W
Indicator F_PANEL HDD LED/POWER LED/RESET/POWER BOTTOM
CIR CIR function
Environment Operating Temp.  -0°C ~ 60°C
Storage Temp.  -40°C ~ 80°C
Operating Humidity  0% ~ 90% relative humidity, non-condensing
Storage Humidity  0% ~ 90% relative humidity, non-condensing
Formfactor Dimensions 100mm * 100mm
Weight 0.45KG
Certificate   FCC, CE, RoHS
