high rate charge/discharge rechargeable 3.2V 50AH Lifepo4 Cylinder Lithium ion Battery Cell
Product Description:
Specification:
3.2V 50AH Lifepo4 Cylinder Lithium ion Battery Cell
| Specification | |
| Nominal Voltage | 3.2V |
| Nominal Capacity(0.5C,25℃) | 50Ah |
| Weight(Approximate) | 1.6kg |
| Dimension(Diameter*Height) | Φ63*219mm |
| Standard Discharge(25℃) | |
| Max. Continuous Discharge Current | 100A |
| Discharge Cut-off Voltage | 2.5V |
| Standard Charge | |
| Max. Charge Voltage | 3.65V |
| Max. Charge Current | 100A |
| Resistance and rates | |
| Internal Resistance | ≤1.5mΩ |
| Self-discharge rate | ≤5% per Month |
| General Features | |
| Cycle life | 2000 cycles (≥ 40AH) |
| Storage temperature | Within 1 month -20~45℃ |
| Within 6 months -20~35℃ | |
Features:
1. Good cell consistency, high Max. charge/discarge pulse current.
2. Low internal resistance, low thermal generated and high safety performance.
3. Good high temperature performance.
4. High capacity, low self-discharge rate and long cycle life.
5. Dimension and type(capacity type and ratio type) can be customized.
Applications:
1. EV: pure electric car, pure electric bus, hybrid electric vehicles, hybrid electric bus, recreational vehicles, chill cars.
2. Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.
3. Power Supply: communication base station power supply, utility power supply, communication industry, emergency power
supply and other system standby power etc.
Product Photos:
Company Workshop:
Laboratory Test:
Packing:
Certificate:
