Help CenterWine Filling Machine
US$ 2,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Beverage
Packaging Type
Bottles
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Power
2.0
Place of Origin
Jiangsu, China
Brand Name
JINRI
Model Number
BGF
Specifications
Wine filling machine1.Capacity:2000-10000b/h
2.Bottle 250ml 500ml 750ml
3,Advanced technology
4.High Efficiency
Wine filling machine
Alcohol Drink / White Wine bottle filling machine / equipment / production line is suitable filling wine,working steable with famous electrical components and working very stable
BGF Wash-filling-capping 3-in-1unit
1.Capacity:2000-30000b/h
2.Bottle 250ml 500ml 750ml etc
3,Advanced technology
4.High Efficienciency
2.Bottle 250ml 500ml 750ml etc
3,Advanced technology
4.High Efficienciency
| Technical Data | ||||
| Model | BGF14124F | BGF18186F | BGF24248F | BGF323210F |
| The number of Washing, Filling, Capping | 14-12-4 | 18-18-6 | 24-24-8 | 32-32-8 |
| Producing capacity; The number of bottle(600ml)/hour |
2000-4000 | 5000-7000 | 8000-12000 | 12000-15000 |
| Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | |||
| Pressure (kg/cm2) | 2~3 | |||
| Motor power (kw) | Main motor 1.5kw | Main motor 2.2kw | Main motor 3kw | Main motor 4kw |
| Outside vacuum pump power (kw) | 0.75 | 1.1 | 1.5 | 2.2 |
| Overall dimension (mm) (LxWxH) |
2100x1400x2500 | 2460x1720x2650 | 3100x2100x2650 | 3500x2500x2650 |
| Weight(kg) | 2500 | 3500 | 4200 | 5500 |
| Technical Data | |||
| Model | BGF404010F | BGF484812F | BGF606015F |
| The number of Washing, Filling, Capping | 40-40-10 | 48-48-12 | 60-60-15 |
| Producing capacity: The number of bottle(600ml)/hour |
16000-20000 | 20000-24000 | 25000-30000 |
| Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | ||
| Pressure (kg/cm2) | 2~3 | ||
| Motor power (kw) | Main motor 7.5kw | Main motor 9.5kw | Main motor 12kw |
| Outside vacuum pump power (kw) | 2.2 | 3 | 4 |
| Overall dimension (mm) (LxWxH) |
4600x1800x2650 | 5200x4500x3400 | 6500x4500x3400 |
| Weight(kg) | 6800 | 7600 | 9800 |
After seal bottle photo
machine photo
