Water Level Control Switch/ Float Level Sensor

Name: Water Level Control Switch/ Float Level Sensor
Brand: BEST
SKU: 131699985
Availability: InStock

US$ 5 - 50 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

BEST

Model Number:

CX-ULM, CX-FLM-FYK

Taizhou Best Electric Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

TAIZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name BEST

Model Number CX-ULM, CX-FLM-FYK

Water level control switch/ float level sensor

What is the introduction of level switches?

1.Muti-point small float level switch (direct mounted with double points and double float)

2.Simple structure , conveniently usage’s level control parts

3.It can control the level for hot water inside the appliance or mechanical equipment or sealed container

What 's the main parameters of float level switches?

Installation	Side-mounted / Top or bottom-mounted (vertical +/-20 ℃)
Installation screw	M10,can customize inG1/8”
Electric connection	300mm, UL1430 AWG22
Bar material	SUS304/316
Float material	SUS304/316
Working pressure	6 Bar
Working temperature	-10~70℃
Accuracy	+/-2mm (in the water)
Repeatability	+/-1mm (in the water)
Switch type	N.C./N.O
Work voltage	250VAC,200VDC, 220VAC
Work current	0.5A/0.7A
Switch power	70VA
Durability	100000times
Float dimension	Dia.28 * dia.9.50*28
