Automatic Bottle Shrink Sleeve Label Machine

Name: Automatic Bottle Shrink Sleeve Label Machine
Brand: JINRI
SKU: 131699485
Availability: InStock

US$ 1,000 - 55,000 MOQ: 1 Piece

Key Specifications

Condition:

New

Application:

Beverage, Other, Beverage, Machinery & Hardware

Packaging Type:

Case

Zhangjiagang Jinri Beverage Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port for automatic bottle shrink sleeve label machine

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage, Other, Beverage, Machinery & Hardware

Packaging Type Case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Electric

Voltage 380VAC

Power 2.5 KW

Place of Origin Jiangsu, China

Brand Name JINRI

Model Number SLM-150

Dimension(L*W*H) 2000*850*2000 mm

Weight 450 KG

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

automatic bottle shrink sleeve label machine

(1)Main parts list

No.	Name	Brand	Producer
1	SUS304 Stainless Steel Material		Korea
2	Motor	T.W.T.	Taiwan
3	Bearing	NSK, MNB,EZO,IJK	Japan
4	Servo Motor	YASKAWA	Japan
5	Servo System	YASKAWA	Japan
6	PLC	OMRON	Japan
7	Transducer	OMRON	Japan
8	Touch Screen	HITECH	Taiwan
9	Contactor	SCHNEIDER	France
10	Sensor	KEYENCE	Japan

(2)Technology parameters:

No.	Item	Data
A	Main Body of SLM-150
1	Dimension(LWH)	20008502000 mm
2	Weight	450 KG
3	Diameter Range of Suitable Bottle	25~125 mm
4	Height Range of Suitable Bottle	35~320 mm
5	Shape of Suitable Bottle	Round or other
6	Length Range of Label	30~180 mm
7	Thickness Range of Label	0.030~0.08 mm
8	Material Range of Label	PVC , OPS , PET
9	Capacity of Output	2000~9000 BPH( bottles per hour)
10	Electricity Consuming	AC 3-phase 380V 50Hz
11	Power Consumption	2.5 KW
B	ST-2000 Shrink Tunnel
1	Dimension(LWH)	2300370(900~1500) (height adjustable)
2	Electricity Consuming	AC 3-phase 380V 50Hz
3	Power Consumption	0.75 KW
4	Working pressure of vapor	0.4 Mpa
C	Vapor Generator
1	Dimension(LWH)	8005001300
2	Weight	80 KG
3	Power Consumption	18 KW
4	Vapor Temperature	171 °C
