2.8mm Galvanized U Shaped Nail Wire

Specifications

2.8mm Galvanized U Shaped Nail Wire
1.Diameter: 2.8mm
2.zinc coat: 45g/sqm
3.Pack: Spool.Coil
4.U shaped nail

2.8mm Galvanized U Shaped Nail Wire



Galvanized Wire is made to AS/NZS 4534 "Zinc and zinc/ aluminium-alloy Coatings on Steel Wire"; BS EN 10244. The metallic zinc coatings applied by the galvanizing process are an effective way of combating corrosion in steel. Galvanized wire for general manufacturing purposes is available in a standard galvanized coating or a heavy galvanized coating.



Additional Info



Diameter Range: Std. Gal. 0.15-8.00 mm
Diameter Range: Heavy Gal 0.90-8.00 mm
Surface Finish: Standard & Heavy Galvanized



Galvanised Wire Working Specifications



Given that galvanized wire is classified according to the amount of zinc coating, the following table outlines the difference between standard, heavy galvanized and extra-high galvanized wire.



Nominal Diameter	Minimum Coating Mass (g/m2)
	Standard Galv.	Heavy Galv.	Extra-highGalv.
over 0.15mm up to and incl. 0.50mm over 0.5mm up to and incl. 0.75mm  over 0.75mm up to and incl. 0.85mm over 0.85mm up to and incl. 0.95mm over 0.95mm up to and incl. 1.06mm over 1.06mm up to and incl. 1.18mm over 1.18mm up to and incl. 1.32mm over 1.32mm up to and incl. 1.55mm over 1.55mm up to and incl. 1.80mm over 1.80mm up to and incl. 2.24mm over 2.24mm up to and incl. 2.72mm over 2.72mm up to and incl. 3.15mm over 3.15mm up to and incl. 3.55mm over 3.55mm up to and incl. 4.25mm over 4.25mm up to and incl. 5.00mm over 5.00mm up to and incl. 8.00mm	15 30 25 25 25 25 30 30 35 35 40 45 50 60 70 80	30 130 130 140 150 160 170 185 200 215 230 240 250 260 275 290	480    485    490 500 520 530 550 590



Tensile Strength (Mpa)



The tensile strength is defined as the maximum load achieved in the tensile test, divided by the cross-sectional area of the wire test piece. Galvanized Wire is produced using soft, medium and hard grade wires. The following table specifies the tensile range according to the grade:



Grade	Tensile Strength (Mpa)
Galvanised - Soft Quality Galvanised - Medium Quality Galvanised - Hard Quality	380/550 500/625 625/850



Please note that the sizes mentioned above are indicative only and do not specify the size range available from my products range.
