LS VISION Outdoor 3 Megapixel Cmos Full-hd Hd-sdi Camera

LS VISION Outdoor 3 Megapixel Cmos Full-hd Hd-sdi Camera thumbnail-1
LS VISION Outdoor 3 Megapixel Cmos Full-hd Hd-sdi Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
LS VISION
Model Number:
LS-VSDI516
Contact Supplier Request Quote Chat Now
Shenzhen LS Vision Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name LS VISION
Model Number LS-VSDI516
Type Digital Camera
Style Bullet Camera
Sensor CMOS
Technology Infrared
Special Features Waterproof / Weatherproof



Product Description



Key Features

       1/3" SONY 2.1Megapixel CMOS Sensor
       1080P(1920 X 1080)@25fps/30fps
       3DNRACCEDefogBLCSense-upDigital ZoomOSD
       3M Pixels Varifocal Lens 2.8-12mm
       4PCS IR LEDS, IR Distance: 40M

Detail display

LS VISION outdoor 3 megapixel cmos full-hd hd-sdi cameraLS VISION outdoor 3 megapixel cmos full-hd hd-sdi camera


Specifications


Model NO

 LS-VSDI516

Image Sensor

1/3" Panasonic COMS (MN34041PL)

DSP

Eyenix (EN773A)

Image Resolution

PAL: 25fps@1080P(1920×1080); NTSC: 30fps@1080P(1920×1080)

Effective Pixels

1920(H) x 1080 (V)

TV System

PAL/NTSC

Electronic Shutter

Auto / Manual / Flicker

Usable Illumination

Color: 1.0Lux/F1. 4, B/W: 0.5Lux /F1. 4; 0Lux /F1.4(IR on)

S/N Ratio

≥50dB

Scanning System

Progressive Scan

Video Output Mode

1CH HD-SDI High-definition Video (1080P or 720P)

Video Output Level

HD-SDI /(1.0 Vp-p 75Ω   ,   Composite)

Focus Length

2.8-12mm

Lens Type

Manual

Pixels

2M Pixels

Auto Iris Support

NO

Infrared LED

4 PCS

Infrared Distance

40M

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Day/Night

Auto (ICR) / Color / B&W

OSD Menu Language

English,Simple Chinese, Traditional Chinese, Japanese, Korea

Wide Dynamic Range

WDR

Defog

YES

Privacy Masking

8 Areas

Digital Zoom

X8

Sense Up

X8

Picture Adjustment

YES, Mirror / Flip / Brightness / Sharpness

UTC Support

NO

Weatherproof Housing

Yes,IP66

Lens Angle Adjustment

YES, 3 Bracket Built-in

Dual Voltage

NO

IR Cut Filter

YES

Heater

NO

Operation    Temperature

-10   °C   ~ +50   °C   RH95% Max

Storage Temperature

-20   °C   ~ +60   °C   RH95% Max

Power Source

DC12V±10%, 500mA

Weight

1.85KG

Application


LS VISION outdoor 3 megapixel cmos full-hd hd-sdi camera
