Conveyor belt
- 2000000 Meter / Meters per Month
- Xingang China.
- T/T D/P D/A
Product Details
Standard or Nonstandard: | Standard | Type: | Flat Belt | Material: | Rubber |
Place of Origin: | Shanxi, China | Brand Name: | AOLUN | Model Number: | ST |
Product Description
Dear Sir/Madam,
Our factory established in 1998, maily handle the export of Wire rope core conveyor belt; Whole core fire retardated conveyor belt; Canvas core conveyor belt; etc. Used for the coal, sea port, etc. Our capacity is 2 million meters, has 600 members, and 60000M2 area. We have very strong ability, and advanced equipment, could produce any kinds of products you needed at the best quality and bottom price.
If you are interested in, please kindly let us know your detailed inquiry, we will try to give you the bottom price soonest possible, also welcome to visit our factory any time.
Anyhow your kindly attention will be appreciated.
ST WIRE ROPE CORE CONVEYOR BELT | ||||||||||||||
Tensile strength(N/mm) | ST630 | ST800 | ST1000 | ST1250 | ST1600 | ST2000 | ST2500 | ST3150 | ST3500 | ST4000 | ST4500 | ST5000 | ST5400 | ST6300 |
Max Wire rope Dia.(mm) | 3.0 | 3.5 | 4.0 | 4.5 | 5.0 | 6.0 | 7.5 | 8.1 | 8.6 | 8.9 | 9.7 | 10.9 | 11.3 | 12.8 |
Distance of wire rope(mm) | 10.0 | 10.0 | 12.0 | 12.0 | 12.0 | 12.0 | 15.0 | 15.0 | 15.0 | 15.0 | 16.0 | 17.0 | 17.0 | 18.0 |
Min thickness of the above cover(mm) | 5.0 | 5.0 | 6.0 | 6.0 | 6.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.5 | 9.0 | 10.0 |
Min thickness of the below cover(mm) | 5.0 | 5.0 | 6.0 | 6.0 | 6.0 | 6.0 | 6.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.5 | 9.0 | 10.0 |
Thickness of the belt(mm) | 13.0 | 13.5 | 16.0 | 16.5 | 17.0 | 20.0 | 21.2 | 24.1 | 24.6 | 24.9 | 25.7 | 27.9 | 29.3 | 32.8 |
Weight of the belt(kg/m) | 18.1 | 19.6 | 23.2 | 25.5 | 27.0 | 33.0 | 37.7 | 42.5 | 45.9 | 48.4 | 51.2 | 57.5 | 61.0 | 65.0 |
800.0 | 75.0 | 75.0 | 63.0 | 63.0 | 63.0 | 63.0 | 50.0 | 50.0 | 50.0 | |||||
1000.0 | 95.0 | 95.0 | 79.0 | 79.0 | 79.0 | 79.0 | 64.0 | 64.0 | 64.0 | 64.0 | 59.0 | 55.0 | 55.0 | 48.0 |
1200.0 | 113.0 | 113.0 | 94.0 | 94.0 | 94.0 | 94.0 | 76.0 | 76.0 | 77.0 | 77.0 | 71.0 | 66.0 | 66.0 | 58.0 |
1400.0 | 133.0 | 133.0 | 111.0 | 111.0 | 111.0 | 111.0 | 89.0 | 89.0 | 90.0 | 90.0 | 84.0 | 78.0 | 78.0 | 68.0 |
1600.0 | 151.0 | 151.0 | 126.0 | 126.0 | 126.0 | 126.0 | 101.0 | 101.0 | 104.0 | 104.0 | 96.0 | 90.0 | 90.0 | 78.0 |
1800.0 | 171.0 | 143.0 | 143.0 | 143.0 | 143.0 | 114.0 | 114.0 | 117.0 | 117.0 | 109.0 | 102.0 | 102.0 | 88.0 | |
2000.0 | 159.0 | 159.0 | 159.0 | 159.0 | 128.0 | 128.0 | 130.0 | 130.0 | 121.0 | 113.0 | 113.0 | 98.0 | ||
2200.0 | 176.0 | 141.0 | 141.0 | 144.0 | 144.0 | 134.0 | 125.0 | 125.0 | 108.0 |
Best RGDS
Pei zhengyang
Shanxi province yangquan metals & minerals imp.& .,ltd.
Tel: 86-353-2023046
Fax: 86-353-2023213
Mobile: 86-13835310865
Email: pzy_30 AT
Skype: pzy750724
Contact Us
- Shanxi Province Yangquan Metals & Minerals Imp. & Exp. Co., Ltd.
- Contact nameGuisheng Zhang
- Phone0086-353-2590004,6667784
- AddressNO.263 TAONAN EAST ROAD Yangquan,Shanxi
