Specifications
led canopy light fixtures1.Light Dimension 603x603 x195mm
2.3years warranty
3.for petrol and oil station
4.explosion proof
2012 hot sale 100w led canopy light fixtures
gas station light LED/ Life Cycle Economies
High LED efficiency reduces energy cost
60,000 +/- hour projected life reduces maintenance
nstant-start LEDs are compatible with inverters and battery back-up emergency
lighting systems available.
petral station lam widely used in gas staiton, tunnel, warehous, parking place
High Visibility Illumination
Extraordinarily uniform illumination
Outstanding vertical footcandles on fuel dispensers as well as on the ground
High CRI, white light enhances visual acuity
Luminaire Housing: White ABS outer housing with steel top cover. Vertical
adjustment brackets allow for leveling and height adjustment. Designed for
recessed installation in double-skin canopies.
Finish: White
Light-Engine Housing: Die cast aluminum housing with heat dissipating fins.
Optical Chamber: Sealed by die formed silicone gasket held captive by stainless steel frame
between clear
prismatic UV stabilized polycarbonate lens and cast aluminum heat sink to prevent
ingress of dust or moisture.
Light Emitting Diodes: Hi-flux/Hi-power white LEDs produce 130 lumens (typical) per
watt and 70% of initial intensity (L70 projection) at 60,000+/- hours of projected life. They have a CCT
(correlated color
temperature) of 5000K and a typical CRI of 70. LEDs are 100% mercury and lead free.
Electrical: Dual power supplies feature a Power Factor of .9 and <20% Total
Harmonic Distortion (THD).
EMC meets or exceeds FCC CFR Part 15 Class A. Power supply produces a
maximum drive current of
325mA to optimize LED efficiency and life. Operating temperature rating: -40F to 122F (-40C to 50C).
Listings/Ratings/Warranties: Luminaires are listed by CSA for use in damp/dry
locations in the United
States and Canada as well as CE listed .
three-year limited warranty is standard on all
components.
Note: CE only 110-220V model
Photometry: IES Type V, Cutoff distribution. All luminaires are photometrically tested by a certified
independent testing laboratories in accordance with IESNA LM-79 testing procedures
Model No. |
GL-OIL002-100W |
Total power consumption |
100W |
Input Voltage |
110~220 V AC |
Working Temperature |
- 20~50 |
Storage Temperature |
- 40~60 |
Color Temperature |
4000~7000 |
Light luminous flux |
7,600 |
Light Dimension |
603 x 603 x 195mm |
Light N.W |
10 |
Light crust |
ABS unibody shell |
Light Body & Shade |
Die cast aluminum radiator fins |
|
warranty
|
3years |
optical design |
IES Type V, Cutoff distribution with None Trapped Light. |
Projector for reference:
