P6 SMD 192X128 Fullcolor Led Digital Signage Display

Name: P6 SMD 192X128 Fullcolor Led Digital Signage Display
Brand: Glare-LED
SKU: 131631207

US$ 1 - 3,000 MOQ: 500 Sets

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Glare-LED

Model Number:

GL-P6(192X128)

Shenzhen Glare-LED Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Glare-LED

Model Number GL-P6(192X128)

Usage Other, outdoor and indoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 6mm

Specifications

led digital signage display
1.High Brightness(2500-4000cd/m2)
2.Energy Saving
3.asynchronous control system
4.hot sale

P6 SMD 192X128 fullcolor led digital signage display

1.Outdoor and indoor Full Color advertising LED display
2.with the high reliability
3.and flexibility is applied for outdoor or indoor

INDOOR FULLCOLOR P6(192X128) led advertising Display
Specifications
Items	Parameter
Pitch	6mm
Pixel Organization	1R1G1B/pixel
Color Depth	13 bit/color
LED type	3528, 3 in 1, SMD
Viewing Angle	120º(H)/ 120º(V)
Brightness	Approx. 2500cd/m2
Resolution Screen	H192 x W128pixels
Playing Software	Video display software
Working Method	Synchronously working with computer or USB flash drives
Dimming Control	16 levels-auto, 256-software
Scan Mode	1/8 Duty
Display Refresh Rate	400 Hz
Out-of-control Pixel	≤0.1‰
Display Area	H1,152mm x W768mm
Casing Size	H1,800mm x W928mm x D218mm
Casing Material & Surface Color	Powder coated steel with front cover
Waterproof Level	IP54 front, IP54 rear
Working Voltage	AC 110V or 220V, 50~60HZ
Led Life Span	100,000hours
Working Environment	-20~+60°C, 10% to 95%RH

outdoor P6 192X128 led advertising display
Specifications
Items	Major Technical Data
Pitch	6mm
Pixel Organization	1R1G1B/pixel
Color Depth	13 bit/color
LED type	3528, 3 in 1, SMD
Viewing Angle	120º(H)/ 120º(V)
Brightness	Approx. 4000cd/m2

Software
Playing Software	Video display software
Working Method	Synchronously working with computer or USB flash drives
Dimming Control	16 levels-auto, 256-software
Scan Mode	1/8 Duty
Display Refresh Rate	400 Hz
Out-of-control Pixel	≤0.1‰

Parameter For the led screen P6 (192*128PIXELS)
Resolution Screen	H192 x W128pixels
Display Area	H1,152mm x W768mm
Casing Size	H1,800mm x W928mm x D218mm
Casing Material & Surface Color	Powder coated steel with front cover
Waterproof Level	IP54 front, IP54 rear
Working Voltage	AC 110V or 220V, 50~60HZ
Led Life Span	100,000hours
Working Environment	-20-+60, 10% to 95%RH
Cabinets	Metal
