DCF Binoculars With Roof Bk7 Prism
US$ 0.1 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jilin, China
Brand Name:
Tianhua
Model Number:
dispersion equilateral prism
Payment & Shipping
Payment Methods:
Port of Shipment:
changchun
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Roof Prism 6.5X32 Waterproof Fogproof Shockproof Binoculars for SaleUS$ 0.1 - 100MOQ: 1 Piece -
Surveying Optical Instruments:BK7 Right Angle PrismUS$ 0.1 - 100MOQ: 1 Piece
-
Customized OEM N-BK9 Right Angle Dielectric Coating Prism MirrorUS$ 0.1 - 100MOQ: 1 Piece
-
Plano Convex Germanium Lens, Optical Infrared Germanium Lens Made in ChinaUS$ 0.1 - 10MOQ: 1 Piece
-
98% Transmittance 44.5mm Optical Plano Convex Glass LENS for LED LightsUS$ 0.1 - 10MOQ: 1 Piece
Place of Origin
Jilin, China
Brand Name
Tianhua
Model Number
dispersion equilateral prism
Material
BK7/K9,B270.ZF4,fused silica,sapphire,IR glass
Triangular BK7 glass dispersion equilateral prism
for pectral analysis experiments and instruments
Description for dispersion equilateral prism
Equilateral prism is also called dispersion prism. Different wavelengths of light through an equilateral prism, they will be dispersed in accordance with the order of short wavelength, so an equilateral prism can be used for spectral analysis.
Specification for dispersion equilateral prism
| Type | Dispersion equilateral prism |
| Material | Fused silica/BK7/K9/quartz |
| Dimension Tolerance | +0/-0.1mm |
| Angle Tolerance | 3 arc min |
| Clear Aperture | >90% |
| Surface Quality | 60-40 scratch and dig |
| Flatness | λ/4 @ 632.8nm |
| Deviation | ±30 arc seconds |
| Bevel | 0.3mmx45deg |
| Perpendicularity | ±2arc min |
| Coating | Upon requirements |
Contact us:
Tel: +86-431-85179189
Package for dispersion equilateral prism
Every product is strongly packed by carton box with foam inside
Shipping for dispersion equilateral prism
will be delivered by International Express: Fedex, TNT, UPS, EMS, DHL.
