Help CenterNew Hopkins Rod Lens Used in Endoscope
Related Products
-
Projector Meniscus LensUS$ 0.1 - 100MOQ: 1 Piece -
Top Fine BK7 Negative Meniscus Spherical LensUS$ 0.1 - 100MOQ: 1 Piece
-
Optical Glass Ball Lenses,half Ball Lens,bk7,fused Silica,sapphire,caf2,znseUS$ 0.2 - 100MOQ: 1 Piece
-
Optical Glass Half Ball Lenses, Dome Magnifier, Paper WeightUS$ 0.2 - 100MOQ: 1 Piece
-
Concave Convex Lens for LED Light LensesUS$ 0.2 - 100MOQ: 1 Piece
Custom optical Cylindrical lens rod lens
optical rod lens
Rod Lenses are a special variant of cylindrical lenses in that they are complete rods where the light passes through the sides of the rod. Rod lenses have an outside face that is polished and the ends ground. Typical uses for rod lenses would be to generate a line image from a circular laser beam.
Rod lenses are polished on the circumference and ground on both ends. Optical performance is similar to a cylinder lens. Collimated light passing through the diameter of the rod will be focused into a line. These components are used in a variety of laser and imaging applications.
Parameters of optical rod lens
1. Material: Optical glass bk7, Sapphire, Pyrex, Fused Silica, IR Crystal etc
2. Clear Aperture: >90%
3. Focal Length: 2mm-1000mm+/-0.2%
4. Size: 0.5-600mm+/-0.02mm
5. Center thickness:0.8-200mm+/-0.01mm
6. Centration: 30''
7. Irregularity: λ/4
8. Surface Quality: 40/20
9. Radius tolerance: +/-0.3%
10. Chamfer: 0.1mmx45degree
our workshop
our company packing
our shipping and payment
