Product Details
| Place of Origin: | Jilin, China | Brand Name: | Tianhua | Model Number: | THCYL-0036 |
| Material: | Other, Glass, N-BK7, H-K9L, ZF51, SF10, Sapphire crystal, CaF2, BaF2, MgF2 etc. | Usage: | Optical | Structure: | Double Convex |
| Shape: | Cylindrical |
Product Description
Cylindrical Lens, BK7 Rod Cylindrical Lenses, Fused Silica Rod Cylinder
Designed for use in a variety of laser and imaging systems, these components are available in a range of micro
sizes for integration into a host of OEM applications. Custom sizes, variations in polishing/ ground surfaces and
additional coatings are available upon request, please contact our Sales Department for details.
Rod Lenses are polished on the circumference and ground on both ends. Optical performance is similar to a cy
linder lens. Collimated light passing through the diameter of the rod lens will be focused into a line. N-BK7 and
UV Fused Silica substrates are available for a variety of UV, Visible and NIR applications.
Specifiction of Our Cylinderical Lens as Follow:
Technical parameters | |
Wavelength | 632.8nm |
Focal length tolerance | ±0.5% |
Diameter tolerance | +0.0/-0.05mm |
Thickness tolerance | ±0.05mm |
Surface accuracy | λ/8 |
Surface quality | 40-20 |
Centration | <1arcmin |
Clear aperture | >98% |
Bevelling | <0.2×45° |
Coating | A: AR Coating 350nm-650nm |
B: AR Coating 650nm-1050nm | |
C: AR Coating 1050nm-1580nm | |
Our Advance Production Line
Contact Us
- Jilin Tianhua Opto-Electrical Technology Development Co., Ltd.
- Contact nameFeng Chen
- Phone86-431-85175526
- AddressHuoju Road No286 Changchun,Jilin
