Help CenterLTA057A341F Toshiba 5.7 Inch TFT LCD Module 320X240 CMOS Interface
Related Products
-
NL10276BC16-06D NEC 8.4 Inch TFT LCD 1024X768 Goods in Stock Brand NewUS$ 100 - 200MOQ: 1 Piece -
LQ121S1LG72 12.1'' TFT LCD Module With Mass StockUS$ 30 - 100MOQ: 1 Piece
-
LQ150X1LW94 SHARP Full View Angle 15 Inch TFT LCD Screen 1024x768 With StockUS$ 10 - 50MOQ: 1 Piece
-
BOE HT185WX1-100 Lcd Panel 18.5 Inch With Lowest PriceUS$ 10 - 60MOQ: 1 Piece
-
Automotive Display LH123WU01 Bar Type 12.3'' 1920x720 LcdUS$ 100 - 200MOQ: 1 Piece
Advantages:
| 1) | wide temperature range -20~70(°C) |
| 2) | low price with stock |
| 3) | RoHS compliant |
| 4) | 100% Original guarantee |
| 5) | 12 months of warranty |
| 6) | industrial LCD ,at least 3-5 years stable delivery |
We can supply total set of display solution:
TFT LCD screen + touch screen + controller board + cables + open frame
| Module number | LTA057A341F |
| Resolution | 320(RGB) x 240 |
| Pixel Pitch | 0.360x0.360 (mm) |
| Active Area | 115.20(W)x86.40(H) (mm) |
| Interface | paralled RGB |
| Outline dimension | 144.0x104.6x8.3(mm) |
| View angle | R/L/U/D 70/70/70/60(Deg) |
| Mode | TN |
| LCD Surface | Anti-Glare, 3H |
| Number of Colors | 262K |
| Brightness | 400cd/m2 |
| Contrast ratio | 500:1 |
| Backlight | WLED |
| Supply Voltage (V) | 3.3V |
| LED backlight | replaceable |
| LED backlight life | >20k hours |
| Response time | 50/50 (Tr/Td) (ms)(Typ.) |
| Operate temperature | -20-70 (°C) |
| Storage temperature | -30-85 (°C) |
Hangzhou LEEHON Technology is established in 2009, nearby beautiful Hangzhou West Lake. We are specialized in supplying clients with professional display solutions. now our products are sold to more than 20 countries, products including monochrome screen, color TFT LCD screen ( GD /Industrial grade, AV /car class, PID /General Application) and we can add other related products such as driver board, control board, cables, inverter and touch panel,open frame etc accessories for our customers.
If you have any question, please contact us
Attn:Susan Wang
Skype: leehon806
Tel: 0086-571-86684288
MP:0086-13136181392
>>Quality ensurance
100% original and brand new, no fake panels exists !
12 months of warranty !
You can enjoy the real panels directly from original factory;
>>Packing ensurance
Original package and Seal for batch orders, all the products are
We have professional support team to provide effective service, we are young and full of passion! in original package from original factory directly, and all the packages have labels and serial number!
>>Delivery ensurance
We have international logistic center in HK, Shanghai and Shenzhen, so we can arrange fastest and most convenient delivery for you !
>>After-Sale service
We have professional support team to provide effective service, we are young and full of passion!
More products' info, welcome to visit our website: !
