EJ080NA-05B INNOLUX 8 inch 800x600 tft lcd display module
| Innolux 8 inch tft lcd (EJ080NA-05B) data sheet | |
| Module number | EJ080NA-05B |
| Resolution | 800 × 3(RGB) × 600 |
| Dot pitch | 0.0675(W) × 0.2025(H) mm |
| Active Area | 162.0(W) × 121.5(H) mm |
| View angle | R/L/U/D 70/70/50/70(Deg) |
| Pixel Arrangement | RGB-stripe |
| Surface Treatment | AG |
| Electrical Interface | Digital |
| Brightness | 250(cd/m2) |
| Contrast ratio | 500:1 |
| Outline dimension | 183.0(W) × 141.0(H) × 5.6(D) mm |
| Backlight | LED |
| Response time | 25(ms) |
| Display mode | TN, Normally White, Transmissive |
| Operate temperature | -20-70(°C) |
| Storage temperature | -30-80(°C) |
| Display Colors | 262k/16.7M |
| Power consumption | 2.138W |
| Power Supply Voltage | 3.3v(Typ.) |
| Backlight lifetime | 20k hrs(Min.) |
| Package | Innolux original package; |
connect with driver board, AD board
1)main brand
We are one of the main agents for AUO/Tianma/Innolux/Mitsubishi/CMI five brands tft lcd moulds in China from 2009, so from here you can get the most competitive price for real products;
2) lcd display panel size range
Lcd panel size range: from 2.2 inch to 24 inch .
3)Quality ensurance
All the panels are 100% original and brand new, no fake panels exists, quality promised; And also Provided 12 months of warranty, you can return any fake panels and charges by us, so from here you can enjoy the real panels directly from original factory;
4)Packing ensurance
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check then;
5)Delivery ensurance
We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from here you can get more convenient delivery;
6)Long-term customers:
Products are sold to more than 20 countries, regular supplier of Marvell(USA), EUROCOMPOSANT(Franch), Jabert Italia srl(Italy) etc., so from here you can get more stable supplying promise;
7)After-Sale service.
Leehon will support original factory technology service before and after sale for all your project.
More products' info, pls welcome to visit our website
Ms. Celia Jiang
Hangzhou Leehon Technology Co., Ltd. .
Tel: 0086-571-86684288
Skype: leehon808
https://img13.fr-trading.com
All emails will be replied within 24 hours. Please leave a message in the Trade Manager. Thank you for ordering and hope you enjoy your purchase here. Your comments are always welcomed and very important in our long-term business corporation
