Plc Control Full Automatic Industrial Water Filter Press

Plc control full automatic industrial water filter press

Brief introduction of  program-controlled auomatic membrane filter press:

The slurry materials are sent to filter chamber by the pressure of feeding pump. Then filtrating media(filter cloth) separates solid and liquid in slurry material. When solid in slurry becomes cake shape, air is sent to diaphragm to fully squeeze the solid to reduce moisture content. If users have high requirements about filtration of sticky material and moisture content ratio, this machine has its own special characteristics to meet the needs.

Membrane Filter Press is more widely used because it reduces subsequent processing or disposal costs of filter cake. In many cases, the membrane filter press significantly reduces moisture content of filter cake, making this technology attractive.

Membrane filter press for various mining sludge: The filter press can be used to process various mine sludge such as gold mine, copper mine, nickel minerals and so on.

Features of automatic membrane filter press:

Automatic  press

Automatic feeding(double feeding) and filtrating

Automatic squeezing

Automatic cake washing

Automatic air blowing

Automatic open

Automatic plate shifting (by groups) and auto cake discharging

Automatic cloth washing--- The washing cycles can be set according to requirements(can be regulated on site)

Automatic drip tray close when cloth washing and filtrating, automatic open when cake discharging.

 Advantages of membrane filter press:

- High product throughput
- Reduction of the residual moisture of the filter cake
- Shorter filtration, wash and cake cycles
- Drier cakes means energy saving on cake drying and transportation
- The optimized cake structure facilities quicker and better washing results
- Varying product quantities and compositions present no problems to the membrane filter press

-  High degree of automation, labor-saving and ease to operate:adopting PLC control system, including automatic keeping pressure, automatic  pulling board, quick program functions,ect.

Specifications and technical parameters of membrane filter press:

 Membrane plates of membrane filter press are made from RPP material moulded. Diaphragm and RPP are enchased togerher to become firm, so they do not fall off easily and have a longer service life.

Membrane plate of membrane filter press

Membrance matching plate of membrane filter press

Membrane filter press or diaphragm filter press with automatic cleaning system

Plate shifting control switch of  membrane filter press

Limit switch of membrane filter press

 Master control of membrane filter press

 Any insterests on our products, please do not hesitate to contact me!
