FL Multifunctional fluid bed granulator/drier/ coater(granule coating machine)

Name: FL Multifunctional fluid bed granulator/drier/ coater(granule coating machine)
Brand: YIBU
Price: USD $30,000 - 60,000 / Set

FOB Price

USD $30,000 - $60,000 / Set

1 Set(Min.Order)

Supply Ability 1 Set / Sets per Month
Port shanghai
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	YIBU	Model Number:	FL
Processing Types:	All kinds of material in powder state	Certification:	ISO9001&14001

Packaging Details

in wooden case

Product Description

Specifications

FL Fluidized Granulator (Fluid Bed Processor)

FL Fluidized Granulator ( granule coating machine )

“YIBU” considers that Fluidized Granulating is an organic combination of mechanical design and manufacture technology. Therefore hundreds of Granulating machines either for China or exported to USA, Japan, Indonesia, Iran and many other countries are designed in accordance with the process of raw materials.

We have manufactured decades specifications and 150 different machines to meet different needs. These practical experiences will be very beneficial to customers.

The flow ability is improved and the dust is reduced, because of Granulator.

Because of powder Granulating, its solubility is improved,

Mixing, Granulator and drying processes are completed in one step inside the machine.

The operation is safe because the anti-static filter cloth adopted.

It's safe for operator if explosion take place, because explosion device is adopted.

No need corner. Therefore the loading and unloading are quick, light and clean, meet the requirements of GMP.

Pharmaceutical industry :tablet capsule, low sugar or no sugar granule of Chinese traditional medicine.
Foodstuff:cocoa,coffee,milk powder,juice of granulate,flavoring and so on.
Other industries:pesticide,feed,chemical fertilizer,pigment,dyestuff and so on.
Drying: powder or granule state of wet material
Coating: protection layer, color, controlled release, film, or bowels solved coating of granules and pills.

The powder granule in vessel (fluid bed) appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.

item		unit	spec
item		unit	3	5	15	30	60	120	200	300	500	1000
vessel	volume	L	12	22	45	100	220	420	670	1000	1500	3000
vessel	diameter	mm	300	400	550	700	1000	1200	1400	1600	1800	2200
capability	min	kg	1.5	4	10	15	30	80	100	150	250	800
capability	max	kg	4.5	6	20	45	90	160	300	450	750	1200
fan	velocity	m³/h	1000	1200	1400	1800	3000	4500	6000	7000	8000	13670
	pressure	mmH₂O	375	375	480	480	950	950	950	950	950	1400
	power	kw	3	4	5.5	7.5	11	18.5	30	37	45	90
steam consumption		kg/h	15	23	42	70	141	211	282	366	451	750
compressed air expenditure		m³/min	0.9	0.9	0.9	0.9	1.0	1.0	1.1	1.5	3.0	4.0
weight of the main body		kg	500	700	900	1000	1100	1300	1500	1800	2500	3500
steam pressure		MPA	0.1-0.4
temperature		°C	adjustable at the range from room temperature to 120°C
working time		min	45-90 decided in accordance with the properties of raw materials
collect rate		%	≥99
noise		dB(A)	≤75dB(A) when do installation ,main machine is separated from fan.
size (L×W×H)		m	1.0×0.6 ×2.1	1.2×0.7 ×2.3	1.25×0.9 ×2.5	1.6×1.1 ×2.5	1.85×1.4 ×3	2.2×1.65 ×3.3	2.34×1.7 ×3.8	2.8×2.0 ×4.5	3×2.25 ×5.0	4×2.8×7.2

Pulse Fluidizing Drying Granulator

Typical customers
Northeast General Pharmaceutical Factory
Heilongjiang Haci Group
Jilin Wutai Group
Hayao Group Sanjing Pharmaceutical Co.,Ltd
Shenyang Tianyitang Chinese Medicines Factory
Beijing Juneng Pharmaceutical Co.,Ltd
Shandong Yuwang Pharmaceutical Co.,Ltd
Shandong LuAn Pharmaceutical Co.,Ltd
Qingdao Liuhe Pharmaceutical Co.,Ltd
Shenzhen Haiwang Food Co.,Ltd
Hunan Hengwei Pharmaceutical Co.,Ltd
Hunan Zhengqing Group Pharmaceutical Stock Co.,Ltd
Yichang Humanwell Pharmaceutical Co.,Ltd
Zhuhai Biochemical Pharmaceutical Factory
Guangdong Yili Pharmaceutical Co.,Ltd
Lijinji (Guangzhou)Food Co.,Ltd
Anhui Renji Pharmaceutical Co.,Ltd
Yunnan Dali Xianglong Pharmaceutical Co.,Ltd
Hainan Xiansheng Pharmaceutical Co.,Ltd
Export USA,Mexico,Indonesia,Iran,Peru and so on


Technical conference for explosion proof fluidized granulator and multi-function coater organized by the Provincial Science & Technology Office of Jiangsu.	USA Daimy Pharmaceutical Co.order two sets of FL200A.	The company had put up big machines including 4 sets of FL500,2 sets of FL300 and 6 sets of FL200 into production at Nanyang,Henan;Tongxiang,zhejiang; Guangxi,sichuan.All of these won good reputation for the company.
