GHL Series Speed Mixing Granulator

GHL Series Speed Mixing Granulator thumbnail-1
GHL Series Speed Mixing Granulator photo-1
US$ 230,000 - 890,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Other, mixing
Product Type:
Detergent Powder
Contact Supplier Request Quote Chat Now
Changzhou Yibu Drying Equipment Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Mixer Type Other, mixing
Product Type Detergent Powder
Application Other, granulator
Additional Capabilities Granulating
Place of Origin Jiangsu, China
Brand Name yibu
Model Number GHL
Max. Loading Capacity 1000L
Voltage according to customer needs
Power(W) 7.5KW
Dimension(L*W*H) 500*500*5~3000*3800*12
Certification CE:UL:FAD:ISO14001:9001
Warranty one years
After-sales Service Provided Engineers available to service machinery overseas
GHL High Speed Mixing Granulator (RMG)




The machine adopts horizontal cylinder structure, its structure reasonable.

Air filled seal shaft for to drive. When washing , it can be changed to water.

Fluidized Granulation, the granule is around ball shape. Its flow ability is good.

Compared to traditional process, 25% of adhesive can be reduced and the drying time is short.

The dry mixing time is 2 minutes and the granulating time is 1-4 minutes. Compared to the traditional process , 4-5 times of efficiency is raised.

Dry mixing ,humid mixing and granulating are finished in the same sealed container. It is in conformity with the requirements of GMP.

The whole operation has strict safe and protective measures.

Jacket type might be adopted on request.




The powder raw material and adhesive in a cylinder are fully mixed at the bottom to become a humid soft material. Then it is cut by high-speed cutter and become uniform granules.



item specification
name unit 10 50 150 200 250 300 400 600
capacity L 10 50 150 200 250 300 400 600
output kg/batch 3 15 50 80 100 130 200 280
mixing speed r.p.m 300/600 200/400 180/270 180/270 180/270 140/220 106/155 80/120
admix power kw 1.5/2.2 4/5.5 6.5/8 9/11 9/11 13/16 18.5/22 22/30
cuting speed r.p.m 1500/3000 1500/ 3000 1500/ 3000 1500/3000 1500/3000 1500/3000 1500/3000 1500/3000
cuting power kw 0.85/1.1 1.3/1.8 2.4/3 4.5/5.5 4.5/5.5 4.5/5.5 6.5/8 9/11
compressed air consumption m3/min 0.6 0.6 0.9 0.9 0.9 1.1 1.5 1.8
weight kg 250 500 800 1000 1300 1800 2200 2600
spec. A B C × D E F
10 270 750 1000×650 745 1350
50 320 950 1250×800 970 1650
150 420 1000 1350×800 1050 1750
200 500 1100 1650×940 1450 2050
250 500 1160 1650×940 1400 2260
300 550 1200 1700×1000 1400 2310
400 670 1300 1860×1100 1550 2410
600 750 1500 2000×1230 1750 2610





Shandong Xinhua Pharmaceutical Stock Co., Ltd.

State Zhongchengyao Engineering Technical Disquisition House

Shanghai Aotejia Biota Co., Ltd.

Dalian Tianlong Pharmaceutical Co., Ltd.

Shanxi Xinshiji Health Protection Products Co., Ltd.

Shijiazhuang Sanjiu Xunli Pharmaceutical Co., Ltd.

Fujian Guangshengtang Pharmaceutical Co., Ltd.

Beijin Qingwutian Pharmaceutical Technology Co., Ltd.

Jiangxi Qingfeng Pharmaceutical Co.,Ltd.

Heilong Group Dinghengsheng Pharmaceutical Co.,Ltd.

Gansu Wuwei Pharmaceutical Co.,Ltd.
