Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof

Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof thumbnail-1
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof thumbnail-2
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof thumbnail-3
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof thumbnail-4
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof thumbnail-5
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof thumbnail-6
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof photo-1
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof photo-2
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof photo-3
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof photo-4
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof photo-5
Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof photo-6
Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
3528
Type:
Flex LED Strips
Input Voltage(V):
12v/24v
Contact Supplier Request Quote Chat Now
Shenzhen Ouge Star Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 3528
Type Flex LED Strips
Input Voltage(V) 12v/24v
Lamp Power 4.8w/m
Lamp Luminous Flux(lm) 4-5
Color Temperature(CCT) 525±2.5
Working Temperature(℃) -10, +45
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
Certification CE
Emitting Color Green
Place of Origin Guangdong, China
Brand Name Star
Model Number ST35G60D65

Specifications

1.Length:1meter
2.SMD3528
3.IP65,drip silicon
4.CE,RoHS
5.Delievry:3-5days

Ruban LED Unicolore 3528 Green DC12V 60led/m IP67waterproof





The STAR FLEX STRIPS are perfect for indirect lighting, as custom made versions for fair or shop applications as well as for all kinds of illumination. Due to their shallow design and the individually adaptable lengths the STAR FLEX STRIPS offer a wide spectrum of application possibilities.







1.High flexibility – adaptable to round shapes.
2.Installation with 3M adhesive tape on the strip’s backside (self adhesive).
3.dimmable or DMX 512, 1-10 V controllable by RGB MULTI power supplies/controller







3528 60led 12v cuttable length:



Ruban LED Unicolore 3528 Green DC12V 60led/m IP65waterproof







Technical Data:



IP classification IP65 for outdoor
Power source 12V DC
Electrical connection 2x cable with 2-PIN to open wires
Maximum quantity per power input 5 M
Operating temperature range –10° C till +45° C
Width x height 8 x 2,5 mm
Cuttable all 3 LEDs (5 cm)







Photometric ata:



LED type SMD Chip 3528
Luminous flux

red 90 Lumen per m
green 170 Lumen per m
blue 60 Lumen per m
amber 90 Lumen per m
white 290 Lumen per m
neutral white 340 Lumen per m
warm white 390 Lumen per m
2700 K 350 Lumen per m
Wave length

red 621 nm
green 527 nm
blue 463 nm
amber 590 nm
Colour temperature

white 6000–8000 K
neutral white 4000–4500 K
warm white 2900–3500 K
2700 K 2500–2800 K
CRI

white 70+
neutral white 70+
warm white 60+
2700 K 60+
Beam angle 120°







Flexible & soft PCB can be bent into any shape, the length can be adjustable or cuttable every three leds







3M Adhesive Tape on the back







Types of waterproof casing are as follows for your choice:



IP20 Non Waterproof
IP65 Drip silicon
IP66 Silicon tube encasing
IP68 Silicone tube and silicon stuffing encasing



IP67  Half-Silicone tube and silicon stuffing encasing



1)Excellent quality, reasonable price
2)CE, RoHS, Outdoor/Indoor
3)Easy installtion
4)Energysaving







FEATURES:
Superbright 3528 SMD top LED, high intensity and reliability.
Long life span 50,000+ hours
Cuttable every 3 LEDs along the cutting marks, according to pratical requirement.
Flexible ribbon for curving around bends
Low power consumption




Applications:
Car decoration
Architectural decorative lighting
Auditorium walkway lighting
Residential Institution Buildings
Schools, Colleges & Universities
Places where energy saving and high color rendering index lighting
Suitable for architectual lighting, cove lighting







Length:5meter each roll,10meters/reel
