Series Diesel Injection Pump & Injector Test Bench

Series Diesel Injection Pump & Injector Test Bench photo-1
Series Diesel Injection Pump & Injector Test Bench photo-2
US$ 4,000 - 7,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Other, Test bench
Voltage:
220/380V/440V
Power:
5.5/7.5/11/15/18.5/ 22kw., Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian China
Delivery Detail:
Delivery time depends on order quantity.
Type Other, Test bench
Voltage 220/380V/440V
Power 5.5/7.5/11/15/18.5/ 22kw., Electric
Certification ISO9001
Applicable Models all injection pump
Brand Name JORI
Model Number JR3000
Warranty 12 Months, 1 Years

Series Diesel Injection Pump & injector Test BenchSeries Diesel Injection Pump & injector Test Bench





Features:



Item:JR3000 diesel fuel injection pump test bench
Color:According to customers' requirment
Brand Name:JORI
Material:Steel
Certificate:CE , ISO9001
Packaging Details:1 set/case
Warranty:12 month
Delivery Time:Within 7 days after receiving payment
Stock:In Stock
Shipping Way:DHL, FedEx, UPS, TNT, EMS, ARAMEX, By Air
Payment Terms:T/T, Western Union, MoneyGram, PayPal, Ect.
Current Export Market:South/North America, Europe, Mid East, Africa, Asia, Australia
JR3000 diesel fuel injection pump test bench details
Series Diesel Injection Pump & injector Test Bench
Series Diesel Injection Pump & injector Test Bench

JR3000 test bench Main function



1. Measurement of each cylinder delivery at any speed.

2. Test point and interval angle of oil supply of injection pump.

3. Checking and adjust the mechanical governor.

4. Checking and adjusting the distributor pump.

5. Experiment and adjusting of behavior of supercharging and compensatory device.

6. Measurement of oil return of distributing pump

7. Testing of the electromagnetic valve of distributor pump.(12V/24V)

8. Measurement of the internal pressure of distributor pump.

9. Checking of the advance angle of advance device.

10. Checking the sealing of injection pump body

11.Install tube of auto-sucking oil supply can check on oil supply    pump(including VE pump.

12. Checking the travel of stroke (on request) USD150.00

13. Advance angle checking.



JR3000 test bench characteristics



1. Changing frequency changing rotational speed

2. Low fall of rotational speed and high output torque

3. High measurement precision;

4. The functions of over voltage, overload and short circuit protection;

5. Ten classes Rotation speeds presetting;

6. Constant temperature controlled;

7. Ultra low noise;

8. Operating position: arbitrary side of the two work sides of the test stand;

9. Rotation speed, count, temperature, air pressure, advance angle are measured and controlled by computers in real time, then displayed by 17″CRT  or on request (17 LCD touch screen).

10. Built-in air resource;

11. All data can be made into reports and printed;

12. Automatically generating and displaying speed characteristics curve; ( tooth bar stroke function on request)

13. The data of the pumps can be saved, modified and obtained pump database;

14. It is very easy to find the data of the pumps in pumps database;



JR3000 test bench specification



No.ItemsData
1Main motor output power(kw) 15KW
2Frequency ConverterWANLI
3Stroke Counting (Rpm)50-9999
4Standard injectors PB55ST42
5Power of fuel pump motor (kw)0.75
6Scope of rotate speed (r/m)0~4000
7Number of cylinders 12
8Height of principal axis center (mm)125
9Filter oil precision of test bench(μ)4.5~5.5
10Volume of big and small volumetric cylinder(ml)150  45
11Volume of fuel tank(L)40
12DC power supply 12/24V
13Low pressure of fuel oil pressure(Mpa)0~0.6
14High pressure of fuel oil pressure(Mpa)0~6
15Pressure Gauge for VE Pump (Mpa)0-1.6
16Pressure Gauge for VE Pump (Mpa)0-0.16
17Control temperature of fuel (℃)40±2
18Flywheel inertia(kg*m)0.8~0.9
19Scope of rack bar stroke(mm)0~25
20Measuring range of flow meter(L/m)10~100
21DC electrical source(V)12  24
22Positive pressure of air supply(Mpa)0~0.3
23Negative pressure of air supply(Mpa)-0.03~0
24Dimensions of Packing ( L*W*H(m ))2.3*1.14*1.73
25Gross weight of Test bench( kg)850Kgs
