Specifications
TMH3.2 Piston Air Motor1.Small in size but high power
2.Variable speed control
3.Stable under extremely conditions
TMH3.2 Piston Air Motor
With compressed air as actuating medium, piston air motor converts the pressure energy of compressed air into rotary mechanical energy.It converts the compressed air energy to mechanical work through linear motion.
Features:
1. High starting torque enables start with load,fast and stop.
2.Simple in structure,small in volum,light in weight,easy in operation and low in maintenance.
3.Stable under inflammable,explosive,outdoor,wet, damp and other extremly conditions.
4.Anti-overload function,automatically reduce to a lower spped until overload relieved and restart,
5.Change air in-let direction in operating valve to get clockwise and anti-clockwise rotation in short time,without any impact to motor and even need not to remove load.
6.Stepless speed change,change rotate speed and power via change air volume.
7.Widely applied in minings, oilfields, constructions,metallurgy,paper making,medicine, chemical industy,smelting,etc. is the ideal mating drive part of Crawler Drills.
Technical Parameters:
Model |
TMH3.2 Piston Air Motor
|
TMH8 Piston Air Motor
|
||||||
Working Pressure (Mpa) |
0.4 |
0.5 |
0.63 |
0.7 |
0.4 |
0.5 |
0.63 |
0.7 |
Idel Speed (R/MIN) |
2170 |
2370 |
2500 |
2600 |
1500 |
1660 |
1750 |
1800 |
Rated Speed (R/MIN) |
1040 |
1140 |
1200 |
1250 |
690 |
760 |
800 |
830 |
Rated Power (KW) |
2.2 |
3 |
4 |
4.8 |
5.8 |
7.7 |
10 |
12.1 |
Air Consumption(L/S) |
53.3 |
67 |
82 |
94.3 |
130 |
164 |
200 |
230 |
