3m 5m One Man Vertical System Lift Disabled Wheelchair Lift

Name: 3m 5m One Man Vertical System Lift Disabled Wheelchair Lift
Brand: TRUE WIN
Availability: InStock

FOB Price

US$ 2,641 - 3,827 / Set

1 Set(Min. Order)

Port QING DAO
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	TRUE WIN
Model Number	LRL0.25-2	Lift Mechanism	Lift Chain
Lift Drive / Actuation	Hydraulic	Power	1.5kw
Rated Loading Capacity	250KG	Min. Lifting Height	60MM
Max. Lifting Height	1200MM	Table Size	1220mm*915mm
Overall Dimensions	1220mm(L)1400mm(W)460	Weight	350KG
Certification	CE / ISO 9001	Warranty	1 YEAR

Product Description

Specifications

1.Load capacity: 250kg
2.CE / ISO9001
3.multi-point control
4.Non-pit installation
5.Emergency lowering
6.vertical lifting structure
7.hydraulic drive,smooth easy

Product Description

1.Vertical elevating system. Suitable for indoor or outdoor applications requiring vertical transportation
2.Easy Installation.It can be directly installed into the ground without architectural supporting pits
3..Easy operate and safety.Its hydraulic or screw system offers passengers smooth and comfortable transportation and different safety devices remove every hiding risk.
4.Emergency descending:When power failure, manually descend the device.

Safety protection device:
(1)Emergency Stop:The lifting and lowering process can be stopped immediately by pressing the emergency button.
(2)Safety device:
Safety Interlock:Lock the platform when it is out of control
(3)Safety Sensor:The operation must be stopped immediately the safety edge meets obstacles during operation.
(4)Emergency lowering:The platform can be lowered by opening hydraulic valve manually or rolling screw rod.
(5)Auto-flap:Turn up after lifting]
(6)Safety Interlocking: The lifting platform shall not run if operates improperly.

Advantages

1.A wheelchair lift is a mechanical device that is designed specifically to transport a wheelchair or motorized scooter and individual from one floor to another. This allows wheelchair users the opportunity to move freely within a multi-floored building while taking the wheelchair with them so they are fully independent between floors.
2.inclined strair climbing lifts (sometimes called a Stair chair lift, stairglide, Stairway Lifts or stair climber) are the perfect, affordable solution to mobility issues with your stairs, making your whole home accessible again. Stair lifts are mainly intended to take persons up the staircase with the ease of usability. The stair lifts are mainly utilized by the people confined to a wheel chair or who have knee problems or other medical conditions which make staircases difficult to climb. Moreover, they are easy to install.
3.It is widely used in residential areas, hotels, administrative offices buildings, subways, banks, stadiums, hospitals and other public places. For the aged and disabled people.
4.Vertical elevating system. This durable and easy-to-use vertical lift is suitable for indoor or outdoor applications requiring vertical transportation up to 6 meters.
5.It can be directly installed into the ground without architectural supporting pits and easy to operate

Technical Parameters

Attention:our products can be made by your needs.

Platform size	1200mm(L)x1000mm(W)
Max Platform Height	1500mm
Min Platform height	80mm
Configuration	Open through or front and side entrances
Speed	60mm/s
Load capacity	250kg~350kg
Control voltage	24V/DC
Power Output	2.2kw
Power Input	220V/50HZ/25A (or customized for local power supply)
Drive System	Hydraulic
Control Mode	Inching Switch or Automatic
Drive Control	Self-resetting system
Overload	Protection Over current relay
Guard panel & drive cabinet (framework)	Aluminum Alloy / 304 stainless steel
Operation Panel	Polished aluminum Alloy
Safety Wane Working Range	75°
Working Condition	Both indoors and outdoors
Working temperature	From -10°~60°C
