Shenzhen Mini GPS Tracker With Waterproof Anywhere for Fleet Management, Personal Tracking

Shenzhen Mini GPS Tracker With Waterproof Anywhere for Fleet Management, Personal Tracking photo-1
US$ 55 - 75 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Other, Gps Tracker, Gps Receiver
Use:
Other, Hand Held, Automotive
Screen Size:
Other, without, No screen
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Type Other, Gps Tracker, Gps Receiver
Use Other, Hand Held, Automotive
Screen Size Other, without, No screen
Function Other, tracking and alarm, GPS tracker
Place of Origin Guangdong, China
Brand Name TRACKPRO
Model Number TR-20, TR20
Warranty 1 Years

Shenzhen mini GPS Tracker With Waterproof anywhere for fleet management, personal tracking









Description:  New GPS/GSM vehicle tracker TR20 with fuel sensor



Model No.: TR-20



*Optional accessories: fuel sensor, odometer sensor, temperature sensor, voice monitor





* Fuel sensor, can know how much fuel used from server, data is very accurate, approximate the real value of the fuel gauge of the car.



* Odometer sensor, the odometer value is approximate the real value of the odometer of the car.



Features:

1) Track by SMS/GPRS

2) Track on Demand

3) Track by Time Interval

4) Track by Distance Interval

5) Track on Mobile Phone

6) get the trajectory playback of the car
7) remotely control the power and door etc of the car.
8) get the direction and condition(ACC on, ACC off, door-pen, door-locked etc) of the cars anytime and anywhere.
9) get the mileage account of the cars.
10) storage data in no GSM signal place

11) built in memory

12) built in backup battery





Alarm functions:
1) over speed alarm, when the truck speed is over your preset value, the tracker will send alarm message to the monitor center or your mobile phone.


2) direction change alarm, when the direction change is bigger than the preset value, the tracker will send alarm message.


3) SOS alarm, when there is carjacking or other emergency issues, the driver can press the SOS button, then the tracker will send SOS message to the center.


4) low battery alarm, when the external battery level is low, the tracker will send alarm message.




5) geo-fence, you can set a scope in the platform, then if the truck is outside the scope, the tracker will send alarm message to center.



6) GPS Antenna Cut Alarm



7) External Power Cut Alarm







Enclosure dimensions

93mm*62mm*25mm

Weight

200g

DC Tolerance voltage

9V - 35V

GSM Module

850/900/1800/1900MHz

GPS Module

SIRF III

Protocol

NMEA0183

Number of Channels

20 Channel Simultaneous Operation

Current (GPRS online)

60mA

Current (GPRS transmission)

80mA

Sleeping mode

40mA

Accuracy Horizontal

<5 meters (50%), <8 meters (90%)

Altitude

<10 meters (50%), <16 meters (90%)

Velocity

0.06 m/sec.

Hot Start:

<13 sec

Warm Start:

<42 sec

Cold Start:

<84 sec

Backup battery

800mAh

Communication

GPRS SMSRS232

Operating Temperature

-20°C to +55°C

Storage Temperature

-40°C to +65°C
