UH-2000 Long Reading Range UHF RFID Handheld - SID Global

Name: UH-2000 Long Reading Range UHF RFID Handheld - SID Global
Brand: SID-Globa
SKU: 131476315
Availability: InStock

Sid Global Sdn. Bhd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Selangor, Malaysia

Brand Name:

SID-Globa

Model Number:

UH-2000

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Kuala Lumpur

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Selangor, Malaysia

Brand Name SID-Globa

Model Number UH-2000

UH-2000 Long reading arange UHF RFID Handheld - SID Global

2-20 M reading range, Big antenna

Product Description

UH - 2000

UHF Gen2

Extra long range

Handheld reader

Applications

Features

Model	UH – 2000
Physical Characteristics	Dimensions	235 (L) x 185 (W) x 185 (H) mm
Physical Characteristics	Weight	580g (with battery)
Environment	Operating Temp	-20°C to 55°C (-4°F to 131°F)
	Storage Temp	-40°C to 80°C (-40°F to 176°F)
	Humidity	10% to 95%
	Casing	IP54
Antenna	Polarization	Linear
	Peak Gain	5 - 12 dbi (selectable on customer’s request)
	Beam Width	Horizontal 3dB Beam width 35°- 90°±2°
	VSWR Ratio	<1.5
Battery Charger	10V 1.0Ah @ 30dBm – 3 hours continuous reading and sending data via BT Fast charging in only 30 minutes
Frequency Ranges	902 or 928 MHz band or upon customer’s request
RF power control	30dBm
Tag Air Interfaces	EPC Class 1 Gen 2
Communication Interface	Bluetooth ™
Reader Range	2-20M
