Self-propelled hydraulic lift / Self-propelled lift
Brief introduction
1.made of high-duty rolled steel
2.CE certificate
3.bigger platform
a.high working capacity, most spacious platforms for several people to work on,easily moved, high working capacity, most spacious platforms for several people to work on,easily moved .
b.. high strength steel structures,smoothly lifting up and droping down, easily operated,few faults.
c.. Moving method:4 wheel mible or 2 wheel towable, tyres are optional, it could be pnumatic rubber tyres,solid rubber tires or polyurethane tires.
The parameter of Hydraulic self-propelled lift:
Model |
ZSJY0.3-6 |
ZSJY0.3-8 |
ZSJY0.3-10 |
Platform height (m) |
6m |
6m |
10m |
Working height (m) |
7.5m |
9.5m |
11.5m |
Guardrail height (m) |
0.9m |
0.9m |
0.9m |
Load capacity (kg) |
300kg |
300kg |
300kg |
Table size (mm) |
1*1.6m |
1*2m |
1.1*2.6m |
Lifting motor power (kw) |
2.2kw |
2.2kw |
2.2kw |
Driving motor Power( kw) |
1.5kw |
1.5kw |
1.5 kw |
Lifting speed (m/min) |
4-6m/min |
4-6m/min |
4-6m/min |
Traveling speed(km/h) |
10km/h |
10km/h |
10km/h |
Grade ability |
30% |
30% |
30% |
Battery |
4pcs 24V |
4pcs 24v |
4pcs 24V |
Voltage (V) |
48V |
48v |
48V |
Tire size(mm) |
300*60mm |
300*60mm |
300*60mm |
Machine weight(kg) |
800kg |
1400kg |
1700kg |
Platform stowed height(m) |
1.2m |
1.4m |
1.6m |
Feature about Self-propelled hydraulic scissor lift
1. Self-propelled hydraulic scissor lift able to work in different condition, without external power supply, without external power traction can lift
2.Scissor lift platform to walk is only one person can complete
3.Convenient movement and make the work high above the more convenient and quick
4.Of dc motor driving wheel has the self-locking function, driving wheel brake separation at work, automatically locked when not working
5.This hydraulic scissor lift of elevator has a mobile and flexible, steady lifting, large capacity, easy to operate
1.The Self-propelled hydraulic scissor lift has battery to go, electric hoist, single, steady lifting operation
2.In the factory or single operation to go aloft working in close range
3.No additional power is needed.
4.Scissor lift of 4 m to 18 m, can be customized according to special size
5.Mobile and flexible, convenient operation, lift
Self-propelled hydraulic scissor lift applicable to the station, docks, airports, stadiums, big enterprise
6.Easily moved, spacious working platforms, smooth working condition and high working efficiency
•Emergency stop buttons at both controls
•Emergency lowering device in case of power supply failure
•24V safe control voltage
•Battery charger indictor
•Forklift pocket
•No-marking wheels
•Low maintenance requirements will save you time and money.
•One hand proportional joystick
We are a professional manufacturer of kinds of Hydraulic Lift in China. Welcome to visit our website for more details
Shan Dong True Win Construction Material Co.,Ltd is a professional manufacturer of aerial working platforms,logistics equipments and handling equipment for logistics ,Our company main products are: Mobile scissor lift, Self-propelled scissor lift, Stationary scissor lift, Aluminum alloy lift , Crank arm type lift, Guide rail lift, and Hydraulic yard ramp,have 8 series and more than 60 varieties.
Q:Who are you? Trade Company or manufacturer?
A: We are manufacturer and we have our own trade company.
Q: When the product can be delivered?
A: Commonly the lead time will be within 15 days after payment.
Q:What’s the Min order to your company?
A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.
Q:What’s the advantage of your company?
A:We have exported our lifts and service to more than 100 countries. We have speclized team work for you, you will get our feedback within 24 hours./ Germany and Italian advancedmanufacturering technology.
Q:What need you know when i inquiry to you ?
A: We need to know your Max Capacity,Platform size and Lift height.
