Home > Electrical & Electronics > Connector & Terminals > Terminals > Wire to Wire Terminal Connector AMP TE Tyco Connector 770902-1 Terminal Wire Connector AWG#26-22
Wire to Wire Terminal Connector AMP TE Tyco Connector 770902-1 Terminal Wire Connector AWG#26-22
US$ 0.0288 - 0.0289
MOQ: 35000 Pieces
Key Specifications
Get Latest Price
Brand Name:
AMP
Model Number:
770902-1
Type:
Crimp Terminal
Payment & Shipping
Payment Methods:
Port of Shipment:
HONG KONG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2.0mm Pitch Connector AMP CT Connector 173977-2 Housing 2 Pin ConnectorUS$ 0.0123 - 0.025MOQ: 1000 Pieces -
TYCO Wire to Wire Connector AMP TE CT Connector 179227-1 Tyco Crimp Terminal ConnectorUS$ 0.025 - 0.035MOQ: 50000 Pieces
-
2.0mm Pitch Connector AMP CT Connector 173977-3 Housing 3 Pin ConnectorUS$ 0.0212 - 0.036MOQ: 1000 Pieces
-
2.0mm Pitch Connector AMP CT Connector 179228-3 Housing 3 Pin ConnectorUS$ 0.01592 - 0.036MOQ: 5000 Pieces
-
Wire to Wire Connector AMP Connector 1-480702-0 Housing Connector 600VUS$ 0.093 - 0.098MOQ: 20000 Pieces
Brand Name
AMP
Model Number
770902-1
Type
Crimp Terminal
Product Description
Product Type Features
| Product Line | Mini-Universal MATE-N-LOK |
| Product Type | Contact |
| PCB Mount Retention | Without |
| Sealed | No |
| Wire/Cable Type | Discrete Wire |
| CSA File Number | LR 7189 |
Mechanical Attachment
| Contact Retention | With |
| Panel Mount Retention | Without |
Electrical Characteristics
| Contact - Rated Current (A) | 11.2 |
| Operating Voltage Reference | AC/DC |
| Operating Voltage (VAC) | 600 |
| Operating Voltage (VDC) | 600 |
Termination Features
| Wire/Cable Size (mm²) | 0.12 – 0.4 |
| Wire/Cable Size (AWG) | 22 – 26 |
| Termination Method to Wire/Cable | Crimp |
Body Features
| Used With | Plug Housing |
| Mating Retention | Without |
| Wire Type | Stranded |
| Assembly Integration Feature | Without |
| Contact Protection Type | Lance |
Contact Features
| Contact Type | Socket |
| Contact Diameter (mm [in]) | 1.80 [0.071] |
| Contact Base Material | Brass |
| Contact Plating, Mating Area, Material | Pre-Tin |
| Shunts/Shorting Bars | Without |
| Multiple Contact Types | Without |
Housing Features
| Mating Alignment | Without |
Configuration Features
| Strain Relief | Without |
Industry Standards
| RoHS/ELV Compliance | RoHS compliant, ELV compliant |
| Lead Free Solder Processes | Not relevant for lead free process |
| RoHS/ELV Compliance History | Always was RoHS compliant |
| VDE Tested | Yes |
| Agency/Standard | CSA, UL |
| UL Rating | Recognized |
| CSA Rating | Certified |
| UL File Number | E28476 |
Environmental
| Operating Temperature (°C [°F]) | -55 – +105 [-67 – +221] |
Conditions for Usage
| Applies To | Wire/Cable |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Accepts Wire Insulation Diameter, Range (mm [in]) | 1.20 – 1.75 [0.047 – 0.069] |
Operation/Application
| Application Use | Wire-to-Wire |
Packaging Features
| Packaging Method | Reel |
| Packaging Quantity | 7,000 |
Other
| Brand | AMP |
| Comment | HDM Applicator part number ending in -3 is used on AMPOMATOR CLS Machine with T or G Terminators, -4 is used on AMP-O-LECTRIC Model K Machine, -5 is used on AMP-O-LECTRIC Model G Machines. |
