SD-CA5500AT PLC Controlled Brushless Industrial Electric Screwdriver

Name: SD-CA5500AT PLC Controlled Brushless Industrial Electric Screwdriver
Brand: SUDONG
SKU: 131472095
Availability: InStock

Shenzhen Kingsom Electronic Business Firm

US$ 150 - 300 MOQ: 10 Sets

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SUDONG

Model Number:

SD-CA5500AT

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SUDONG

Model Number SD-CA5500AT

Power Source Electricity

Type Magnetic Screwdriver

Rated Voltage 30V

Rated Input Power 35W

Max. Torque 19 Kgf.cm / 1.86 N.m

No-Load Speed Hi: 1000R.p.m, Lo:650R.p.m

Dimensions Length:220mm

Specifications

SD-CA5500AT PLC controlled electric screwdriver
1.CE Approved Fully Automatic
2.Machine use type,brushless
3.Assembly device

Performance of SD-CA5500AT PLC controlled Automatic brushless electric screwdriver :

1. It is a built-in high performance carbon brush with magnetic motor.

2. The high-precision magnetic brake and external automatic control circuit are patented and easy for maintenance.

3. Durability is excellent and it can withstand the long continuous fastening screws.

4. The re-torque is high-precision with high reliability of the fastening screw.

5. Can be directly by external PLC control and connectivity of the intelligent power controller.

6. Torque adjustment is easy and convenient step-less adjustment by rotating the torque adjustment ring to the left or to the right.

7. Four screwdriver heads (A,B,C, and D) are available.

8. It can be used for mobile phones,digital cameras,MP3,laptops,printers,copy machines and other screw fastening products.

9. Certification: CE,CCC,ROHS and ISO9001:2008.

Specification

Model		SD-CA5500AT	SD-CA6000AT	SD-CA7000AT
Input voltage		DC 30V
Torque range	(Kgf.cm)	5-25	5-25	15-45
	(Lbf.in)	4.4-22	4.4-22	13.2-39.62
	(N.m)	0.5-2.45	0.5-2.45	1.47-4.41
Torque accuracy	±3%
Torque adjustment	Stepless adjustment
No-Load Speed(r.p.m) ±10%		1000	1000	500
		650	650
Application power adapter		SD-40A
Rating Power(W)		35W	60W
Screws diameter(mm)	Machine screw	2.6-4.0	2.6-4.0	4.0-6.0
	Self-Tapping screw	2.6-3.5	2.6-3.5	4.0-5.0
Length(mm)		220	250
Application to the 90 degree adapter		SD-Q2	SD-Q3
