Home > Products > molex > Tin (Sn) over Copper (Cu) Plated Brass molex connector 39-00-0040 male crimp terminal 5558 series 18-24 AWG
Tin (Sn) over Copper (Cu) Plated Brass molex connector 39-00-0040 male crimp terminal 5558 series 18-24 AWG
USD $0.0097 - $0.015
/ Piece
4000 Pieces(Min.Order)
- 1040000 Piece / Pieces per Month
- HONG KONG
You May Like
-
Cat Ear Crimp Terminal 4809 series molex connector 08-50-0031 female crimp terminal 22-30 AWG Hot Tin Dip
-
Crimp Terminal 2759 molex connector 08-55-0101 female crimp terminal 22-30 AWG Selective Gold (Au) Nickel (Ni) Under Plating
-
electronic component Crimp Terminal 44476 series molex wire to board wire to wire female wire connector 44476-3111
-
wire to board crimp connector wire to wire connector board to board connecor molex connector terminal housing SUPERIA spots
-
electrical 2.0mm pitch connector crimp terminal female molex 50212 series connector 50212-8000 24-30AWG reel
-
1.5mm pitch electronic component molex 87421 series connector crimp terminal female 87421-0000 24-30AWG reel
Product Details
| Brand Name | molex | Model Number | 39-00-0040 | |
| Type | Crimp Terminal |
Product Description
Product Description
Part Number: 39-00-0040
Mini-Fit® Male Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass Contact, 18-24 AWG, Reel
| Durability (mating cycles max) | 30 |
|---|---|
| Gender | Male |
| Material - Metal | Brass |
| Material - Plating Mating | Tin |
| Material - Plating Termination | Tin |
| Net Weight | 0.123/g |
| Packaging Type | Reel |
| Plating min - Mating | 0.889µm |
| Plating min - Termination | 0.889µm |
| Termination Interface: Style | Crimp or Compression |
| Wire Insulation Diameter | 1.30-3.10mm |
| Wire Size AWG | 18, 20, 22, 24 |
| Wire Size mm² | N/A |
