WCB300 Stabilized Soil Mixing Plant Engineering & Construction Machinery

FOB Price

US$ 42,000 - 60,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Shandong, China	Brand Name	zeyu
Model Number	WCB300	Power(W)	no
Dimension(LWH)	no	Weight	no
Certification	ISO	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

WCB300 Stabilized soil mixing plant Engineering & Construction Machinery

The WCB series stabilized soil mixing station sets of special equipment for continuous

mixing of road base materials, the device is absorbed by the domestic and foreign

continuous stable soil mixing station advantages on the basis of self-developed products,

it is suitable for the construction of high grade the mixing of road base materials for roads,

airports, docks and other facilities.Compared with other devices that have the following

characteristics:

1.1 host continuous twin-shaft mixer, mixing uniformity;

1.2 mixing four different specifications, different varieties of materials, preparation of a

variety of stabilized soil mixture ratio;

1.3 centralized control, manual, automatic, easy operation, good reliability;

1.4 modular structure, easy installation and transportation;

1.5 Ingredients with high precision batching belt scales, accurate measurement, the ratio of

rapid change

Parameter model	WCB300	WCB400
Productivity	300t/h	400t/h
Total power	95kw	108kw
largest grain size	60mm	60mm
charging height	3800mm	3800mm
discharging height	3600mm	3600mm
Aggregate measurement accuracy	±2%	±2%
Powder measuring accuracy	±1%	±1%
water measuring accuracy	±1%	±1%
shape dimension(mm)	42500×14000×18000	42500×14000×18000
