China Brand JZC Series Cheap Price of Diesel Engine Cement Concrete Mixer Machine for Sale
Main Technical specifications
Discharge volume(L) : 350
Arge volume(L) : 560
productivity(m3/h) :12-14
mixing motor:
Model:Y132S-4
Powe(Kw):5.5
rotate speed(r/min): 1440
water pump motor:
Model:50DWB20-8A
power(Kw):0.55
rotate speed(r/min): 2800
mixing barrel rotate speed(r/min):14.5
Particle size of the largest aggregate (gravel/pebble) mm :40/60
mixing time(S): 35-45
Dimension:2550×2230×3050( on working)
2650*2230*2700 (on transportation)
weight (kg) :1920
Diesel engine Main technical parameters
Model: ZS1115M
Type: horizontal, single-cylinder, four-stroke
Cylinder diameter: 115mm
Piston displacement: 1.195
Rated power: 14.71KW
ISO standard fuel stops power (icfn): 16.18kw
Rated speed: 2200r/min
Cooling: Evaporative
Start: Electric start
Battery: 12V Maintenance-free lead-acid battery brand
Net weight: 195kg
Dimensions: 970 × 463 × 699mm
Generator main technical parameters:
Model: STC-15
Power: 15KW
Current: 27.1A
Poles: 4
Frequency: 50 Hz
Power factor: 0.8
Speed: 1500r/min
