Description of WPC foam sheet
JIYUAN WPC foam sheet is expanded, cellular PVC, like wood. But it’s better than wood.
More than just a smooth finish, JIYUAN WPC foam sheet is a sealed edge that resists staining from dirt and grime and easily wipes clean if dirt should come in contact with the boards.
Features of WPC foam sheet
Advantages:
1. High integrity, good performance of intensity, stable size, high toughness of surface, attrition resistant, easy to be washed; able to endure the weight of 400-500Kg per kilometer and different kinds of construction pressure.
2. Hot resistant, cold resistant, anti-aging, the surface is smooth, could be used between 60—100 times, with big applying temperature range from -15 to 50 °C.
3. It is very convenient to processing and also can improve the speed of construction. It is not strict to the worker’s grade.
4. The appearance is clean and smooth, can save the money for plastering and the fee of material, save the time of construction.
5. It can be recycled after usage.
6. The gap between board and board is no more than 2mm; it can be piece together integrity any size of the room in the course of constructing.
Chief Specification Parameters
Product Name |
WPC foam sheet |
Raw Material |
PVC and Wood powder |
Size |
1220*2440mm or as order |
Thickness |
2~ 20mm |
Color |
Wood grain, stone grain or as order |
Density |
0.50-0.90 g/cm3 |
Tolerances |
+/- 0.03 on densities -0 to +3mm on width |
-0 to +5mm on length +/- 2% on thickness |
|
Export Market |
Global |
||
Remarks:
--Other sizes, grain can be customized
--Length, width, and thickness tolerances may vary by manufacturer
--Certain grades available in various grains
--Minimums may apply to certain materials
Typical Properties:
Properties |
Unit |
Value |
Specific Gravity |
g/cm³ |
|
Hardness |
Shore A |
40-98 |
Tensile strength |
MPa |
5-20 |
Elongation at break |
% |
5-30 |
Impact strength of simply supported beam |
KJ/m² |
10-30 |
Vicat softening temperature |
°C |
77.7 |
Heating Size Variance Ratio |
% |
0.008 |
Water Absorption |
% |
0.066 |
Bending strength |
MPa |
20-70 |
Wear ability (rolling friction) |
mg/1000turning |
57 |
Coefficient of linear thermal expansion (from -40°C 48h to +40 °C 48h) |
--- |
No crack flaking off and deformation |
Impact strength by falling boll |
--- |
No crack by impact of a 1kg steel ball with a drop of 1meter |
Compared with bamboo plywood and laminated multilayer board
Performance |
WPC Foam Board |
Bamboo plywood |
Laminated multilayer board |
Fire resistance |
Yes |
NO |
NO |
Recyclability |
Yes |
NO |
NO |
Water absorption |
No deformation |
Deformation |
Deformation |
Demoulding |
Easy |
Difficult |
Difficult |
Stripping process |
Easy |
Difficult |
Difficult |
Bespoke size |
Accepted |
Not accepted |
Not accepted |
Acid-alkali-corrosion-proof |
Super |
Poorer |
Poorer |
Abrasion proof |
Yes |
NO |
NO |
Surface processing charge |
Low |
High |
High |
Optional in various grains
Application of WPC foam sheet
FURNITURE DECORATION
Bath ark, ambry, Decorative board,noise barriers,partition board,roof insulation board,fire-resistant kitchenware and bathroom facilities,commerial decorative shelf,clean room dampproof,wall and fireproof window frame.
ARCHITECTURAL TRANSPORTATION
Upholstery for steamship, bus, train, ceiling, anti-vibration of container and moisture-proof insulation.
ADVERTISING
Professional screen printing, exhibition board, High-end merchandise display rack, color sign, signboard.
INDUSTRY ENGINEERING
Moisture protection, corrosion protection, environment protection special insulation and pieces of hot forming.
OTHERS
Cold storage, anticorrosion material, energy saving device, chemical resistant material, water resistant template,antistatic facility, seashore damp-proof facility,and various light partiions.
Warranty
We have a complete quality management system. All of the products are under very strict quality control.
We focus on each details of our products!
As professional of WPC foam sheet manufacturer. JIYUAN has formed a set of complete procedure & system from selecting suppliers, inspecting raw material, monitoring production process and testing product, thus to provide the high-quality & stable product to customers.
