chemical resistance sus 304 vertical mounted float level switch
- 5000 Piece / Pieces per Month
- Dongguan
- Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | RGP | Model Number: | 1075-S |
Product Description
1075-S float level switches
Description
3. 1075-s technical Parameter.
Max contact Rating | 10 W | 50W |
Max switching voltage | 200V DC | 300VDC/250VAC |
Max switching current | 0.5 A | 1A |
Max carry current | 1.0A | 1.5A |
Thread Diameter | M10 | |
The main material | sus304 | |
The float material | sus304 | |
Float SG | 0.75 | |
Lead wire | Length 30cm | |
Approvals | ROHS |
The customer service
The float level switch utilized the float with magnetic filed an reed switches , One or more reed switches are placed in at a specific height inside a guide tube. The changes in liquid level modify the float position in this guide tube, so that when it reaches the switch position, it changes its status ,providing an output signal for level detection.
General information
- Switches should be installed rigidly so that float or floats are free to move as the liquid level changes.
- Switches should be mounted in a tank area free of severe turbulence turbulence or protected from such turbulence by appropriate and adequate slosh shields.
- Vertical switch stems should be vertical for best results, but satisfactory operation is possible in most liquids with the stem at up to a 30 degree angle from vertical..
- Care should be taken that switches are always operated within electrical ratings.
- Orientation for standard vertical switches can be changed from normally open to normally closed dry or vice versa by removing the float and reversing in the stem.
Maintenance should consist of inspection to see that the float is free to move and coated with any substance , which would change its weight or volume significantly. IF this occurs, this float should be cleaned .This is easily accomplished without disturbing the installation . In addition , the stem may be wiped down to remove any buildup.The only repair possible in the field is replacement of either the float or stem . Dents or nicks on the float are usually of no consequence to operation.
The side mounted float level switches series
The packing of the goods
E .Application:
Float level switches are widely used in different ares.
About us
Jinhefeng industrial electrical co., ltd is devoting to designs and manufacture the sensing switch for more than 10 years .we have striven and now provides some of the best sensor solutions for liquid level, flow control , for the most demanding float switch applications. Whether you need a single point float switch or continuous liquid level sensor, JHF Company can direct you to the proper float switch and liquid level sensor solution. Our Company offers standard float switch sensors in stock for same day shipment, and can also custom configures multiple-point float level switches in only 5 days.
We can combine our wide range of sensing technologies with numerous material choices to fit almost any application. We have material choices such as stainless steel, Polypropylene,PVC , Teflon ,copper etc. to ensure that you are provided with a sensor that will provide durability and long life.
The float switches are stand up to harsh environments, hazardous locations and pressures,sanitary and food grade, that designs meet agency approvals like ROHS and ISO.
Whether you need a float switch, continuous liquid level sensor, pressure or temperature sensor, utilized in Water and Waste Water Tanks, Food and Food Processing Equipment, HVAC, Specialty Vehicles, Medical, Marine, Washing Equipment, or any Industrial Application, let JHF provide it.
The float switch delivery cargo and the payment.
During the international fair for float level switches
Questioa and answer
1: How soon can we get a sample of the sensing switch?
A : We have usual models(float switches in stock,it can be sent to you within 1-2 working days. and the order depend on how many pis you need.let us discuss it.
2: What is the payment terms?
A :We can accept T/T and L/C at sight payment.
3: Can the logo or company name or the pattern to be printed on the products or package?
A : Sure.Your logo or company name or pattern can be printed on your products or package by printing,etching,or sticker,
4: Can we choose color of the product?
A : Yes,please discuss with us.
6: Can package be change?
A : We have professional designer that can help you to design beautiful product
package for your product.
7: Can you help us to develope our own product?
A : OEM project is welcome, we have professional workshop for doing OEM project.
8: How can you guarantee quality of your product?
A : Quality is our life!And the level sensor are stable and reliable.
For every product, we have passed more than one hundred time of inspection, because QC checking on each production process.
9: MOQ?
A :Usually for the special order (OEM) 100pcs is the least ,but for the usually products you can choose any piece,but we can also talk in detail.
