Description
Figure 1 Figure 2
A: The components.
1: The main stem material: PP plastic
2. The float material: PP
3. Assembly: Reed switch magnet Epoxy
4. Lead Wire.30 cm(Teflon).
B: Working principle:
The side-mounted float level switch is to use liquid buoyancy principle, along with the liquid level ,the duckbill
float will move up and down ,the it will trigger the reed switch that sealed in the junction box ,the magnet arm
will be affected, and for turning connect (ON) or disconnect (OFF).
C:The installation instructions (see Figure II)
1.on the both sides tank,side mount, No( open) or NC (closed) by reversing 180 degrees.
2.2. The total length of L5-P is 87 mm, the diameter of the connector thread is 16mm, length is 8mm, height is 5mm ,hex stem length
23mm, duckbill(float ball body ) length is 50mm.
3. Unscrew the nut, plug out from the inside out (with a white envelope apron) together, and tighten the
nut.
D: Instructions
1: The range of temperature -30 ℃~ 80 ℃
2: Suit for corrosive liquid, and the viscosity of the liquid is not high stick, won’t be dry.
3. Parameter.
Max contact Rating |
10 W |
50W |
Max switching voltage |
200V DC |
300VDC/250VAC |
Max switching current |
0.5 A |
1A |
Max carry current |
1.0A |
1.5A |
Thread Diameter |
16mm(M16) |
|
The main material |
PP |
|
The float material |
PP |
|
Lead wire |
Length 30cm (Teflon) |
|
Approval |
ROHS |
|
E Application:
Suit for a variety of food and beverage equipment ,medical equipment and industrial equipment,
such as household appliances, humidifiers, chillers, fog machine, constant temperature and humidity
level detection machines, printing machines, medical equipment, beverage machinery, and pressure
tank, the signal remote switch police, health, environmental, toxic, corrosive liquid with acid use.
