Cost price competitive cattle loading ramp trailer
Mobile Motorcycle Lift Ramp
Mobile Dock Ramp- height adjustable ramps, used as a bridge between dock and trucks, can be operated via mechanical (spring), hydraulic, or air powered systems.
Dock ramps are bridges between a truck and a warehouse to safely accommodate a forklift.
Where it is not practical to install permanent concrete loading docks, or for temporary situations, then it is common to use a mobile version of the loading dock, often called a yard ramp.
- The platform are fully hydraulic drive,easy operation, operational reliability.
- Their height vary with the change of the height of the wagon box, and they keep close
- contact with
- the wagon box all the time.
- The platform is high strength U shaped beam design,which guarantees that it will not
- deform under
- high load and long time operating.
- The surface board of the platform is antislip ruffled plate,which can guarantee that forks will not slip when driving on the platform.
- Both sides of the platform are fitted with safety guard board to prevent tiptoes from being
- accidently
- injured when stretching into the platform.
- The hydraulic yard ramp has a safety support rod that enables the platform to stay opened, allowing
- personnel to get inside the leveler to do maintenance work convenientl
Description of cattle loading ramp trailer:
| model | loading capacity(kg) | variable range(mm) | ramp length (mm) | ranp width (mm) | wheel trath(mm) | hand times | weight (kg) |
| SJDQ6-0.9 | 6000 | 900 | 10500 | 2000 | 1500 | 50 | 2100 |
| SJDQ8-0.9 | 8000 | 900 | 10500 | 2000 | 1500 | 50 | 2300 |
| SJDQ10-0.9 | 10000 | 900 | 10500 | 2000 | 1500 | 50 | 2500 |
| SJDQ12-0.9 | 12000 | 900 | 10500 | 2000 | 1500 | 50 | 2700 |
| SJDQ15-0.9 | 15000 | 900 | 10500 | 2000 | 1500 | 50 | 3200 |
Picture of cattle loading ramp trailer:
3. One Year Quality warrant service, during the period spare part supplied free if you pay for shipping.
4.Professional team supply service for life long time.
A. Daily or refueling: Check the parts are good or bad Check hydraulic oil level and colour
B. Every 250hours or 3months: Change lubricating oil Check cylinders
C. Every 500hours or 6 months: Check tubes, pipes and value
D. Every 1000 hours or 1 year: Change hydraulic oil Grease rotation bearing and wear pads
E. Every 2000 hours or 2 years:Check hydraulic tank, lid and vent
F. Note: Maintain the chassis according to the Chassis’ Service manual
FAQ:
Q:Who are you? Trade Company or manufacturer?
A: We are manufacturer and we have our own trade company.
Q: When the product can be delivered?
A: Commonly the lead time will be within 15 days after payment.
Q:What’s the Min order to your company?
A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.
Q:What’s the advantage of your company?
A:We have exported our lifts and service to more than 100 countries. We have speclized team work for you, you will get our feedback within 24 hours./ Germany and Italian advancedmanufacturering technology.
Q:What need you know when i inquiry to you ?
A: We need to know your Max Capacity,Platform size and Lift height.
cattle loading ramp trailer
