Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000

Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000 photo-1
Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000 photo-2
Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000 photo-3
Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000 photo-4
Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000 photo-5
Top Manufacturer and Exporter of Twin-shaft Compulsary Concrete Mixer JS1000 photo-6
US$ 18,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
ZEYU
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name ZEYU
Model Number JS1000
Motor Power 2*18.5 kw+18.5 kw+3 kw
Mixing Power 2*18.5KW
Charging Capacity 1600L
Reclaiming capacity 1000L
Speed of Mixing Drum 25.5 r/min
Water Supply Mode Pump
Working Cycle Period 35-45s
Discharge Way Automatic
Outline Dimension 3164*2000*1491mm
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Application

top manufacturer and exporter of twin-shaft compulsary concrete mixer JS1000

China Factory Price JS1000 Electric Fixed Concrete Mixer can be used independent and also be used as the part of the concrete batching plant,it can apply to kinds of construction site and precast parts factory.

Model
JS1000
Charge volume(L)
1600
Discharge volume(L)
1000
Productivity(m3/h)
≤50
Aggregate diameter (mm)
80/60
Mixing blade speed(r/min)
25.5
Mixing blade quanity
20
Mixing motor  model
Y200L1-6-18.5
Hoisting motor model
YEZ180M-4-18.5
Water pump power (kw)
3
Hopper hoisting speed(m/min)
21.9
Overall dimension (mm)
8765*3436*9540
Total weight (kg)
8750
Discharge height (mm)
1600/2700/4800

Main Features

1) Small linear velocity, good abrasion resistance and low energy cost, good mixing quality, high production efficiency, easy operation, ease to maintenance, low power cost and long life for quick-wear parts;

2) It can be used for mixing kinds of the concretes such as hard concrete, plastic concrete, fluid concrete, light aggregate concrete and other kinds of mortars.

3) The components of the mixer includes the mixing equipment, driving device, discharging device, charging device, lubricating system, control system and so on.

Certifications
Detailed Images

Machine Parts

Name: JS1000

Brand: ZEYU

Original: China

The whole mixer body is bored by the boring machine, to keep the concentric degree of the mixing axle.

Main Features

Name: JS1000
Brand: ZEYU
Original: China
The rubber sealing gasket of the axle end seal is installed at side of the mixing arm, normally it can mixing 200 thousand time without mortar leakage.

Machine Parts

Name: js1000
Brand: ZEYU
Original: China
The discharging opening adopts arch structure with the Scraper,the machine can work for arch leveling and work in steady,to prevent the material bejammed by the discharging opening.

Main Features

Name: JS1000
Brand: ZEYU
Original: China
The lubrication and seal of the axle end adopt the electrical concentrated oil pump to lubricate automatically.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
4640*2250*2250mm
Weight
8750kg



Packaging Details
The normal package is container.
