About Movable electric powered articulating boom lift with CE, ISO :
1. Maneuverability In Narrow Space
Movable electric powered articulating boom lift with CE, ISO Certificate contain several compact models which allow you to operate the machine in limited space. With narrow design and zero-radius system, barriers can be easily passed,more space left for running machine.
2.Exclusive Advanced Control System
With well-designed control system, you can precisely and smoothly operate the boom lifts. Multi-motion control allows you to operate several actions simultaneously.
Product overview of Movable electric powered articulating boom lift with CE, ISO:
Crank arm lift'paremeters:
| model | LHSJZ-6 | LHSJZ-8 | LHSJZ-10 | LHSJZ-12 | LHSJZ-14 |
| max working height | 7.7 | 9.7 | 11.7 | 13.7 | 14.7 |
| max working radius | 1.5 | 2.2 | 2.7 | 3.2 | 3.5 |
| rotation range | 360° | 360° | 360° | 360° | 360° |
| loading capacity | 160 | 160 | 160 | 160 | 160 |
| overall size | 2.3*0.9*2.1 | 3.0*1.2*2.5 | 4.0*1.7*3.0 | 5.0*1.9*3.0 | 5.5*2.0*3.0 |
| weight | 1500 | 1700 | 1800 | 1900 | 2000 |
| lifting speed | 0.04-0.07 | 0.04-0.07 | 0.05-0.09 | 0.05-0.09 | 0.05-0.09 |
| working pressure | 10 | 10 | 10 | 10 | 10 |
| walking speed | 15-20 | 15-20 | 15-30 | 15-30 | 15-30 |
| anti-wind capacity | ≤5 level | ≤5 level | ≤5 level | ≤5 level | ≤5 level |
Features of Movable electric powered articulating boom lift with CE, ISO:
1. Self lubricating axle pin
2. Proportional control system
3. Foam filled tire
4. All motion alarm
5. Battery condition indicator
6. 3 °Tilt alarm and platform of overload warning system
7. Elevate bracket
8. Foot-switch linked and joystick control
9. Lockable platform control cover
http://www.china.cn/product-detail/Hydraulic-mobile-boom-lift-Crank-arm_60294244801.html?spm=a2700.7724838.35.1.zSiXhb
A. Daily or refueling: Check the parts are good or bad Check hydraulic oil level and colour
B. Every 250hours or 3months: Change lubricating oil Check cylinders
C. Every 500hours or 6 months: Check tubes, pipes and value
D. Every 1000 hours or 1 year: Change hydraulic oil Grease rotation bearing and wear pads
E. Every 2000 hours or 2 years:Check hydraulic tank, lid and vent
F. Note: Maintain the chassis according to the Chassis’ Service manual
FAQ:
Q:Who are you? Trade Company or manufacturer?
A: We are manufacturer and we have our own trade company.
Q: When the product can be delivered?
A: Commonly the lead time will be within 15 days after payment.
Q:What’s the Min order to your company?
A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.
Q:What’s the advantage of your company?
A:We have exported our lifts and service to more than 100 countries. We have speclized team work for you, you will get our feedback within 24 hours./ Germany and Italian advancedmanufacturering technology.
Q:What need you know when i inquiry to you ?
A: We need to know your Max Capacity,Platform size and Lift height.
