Industrail freight goods lift

FOB Price

USD $3,000 - $6,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port QINGDAO
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	True win
Model Number	SJD	Lift Mechanism	Telescoping Lift
Lift Drive / Actuation	Hydraulic	Power	3kw
Rated Loading Capacity	2000kg
Max. Lifting Height	As your need	Table Size	1500*2000mm, optional
Weight	2000kg	Certification	CE ISO
Warranty	1 Year	After-sales Service Provided	Overseas third-party support available

Product Description

General description and advantages:

1. Chain lifting platforms, with flexible lifting range, large loading capacity, are compact and light weight.

2. Without restriction of space, they are widely used in lifting operations over large areas, such narrow space as warehouses, factories, highways and stairwell place where we could not dig pits.

3. The platform moves smooth, operates simply, safely and reliably.

Power driven:

The usual power supply is external connection electricity variety of 220v, 380v, 400v. and they also

can be equipped with handle control, in case the power is not available that the lift can work.

Changeable items:

1. The control button is all put on the ground panel, but they can be changed onto the platform or

controlled by a remote controller.

2. The power supply can be changed to Hydraulic driven power to meet the need where the electricity is not available.

Supplying capacity:

We have regular models of lift kept in our warehouse, they can be delivered as soon as the order

comes. Or we manufacture the machine according to the order that the customer gives with special

design.

Guide cargo lifter is mainly used for conveying cargos up and down between various working layers work

layer .

Model	Capacity(kg)	Vertical Travel(mm)	Min.height(mm)	Platform size(mm)	Mating power(kw)
SJD1.0-4.5	1000	4500	250	1500*1600	2.2
SJD1.0-1.4	1000	14000	250	1800*1400	3
SJD1.5-5.0	1500	5000	250	1620*1520	3
SJD2.0-5.0	2000	5000	250	1600*1500	3
SJD3.0-5.0	3000	5000	300	2000*1800	3

Our Services

1. Presale service: Free comprehensive and detailed technology consultancy in construction sites, referential programs for construction equipment and the most suitable product program.
2. In sale service: We provide free guidance of installation and debugging and free training of operation, care and maintenance.
3. After-sale service: One year warranty service of whole machine and lifetime maintenance; regularly markets visits and free guidance of whole machine’s maintenance and reparations.
4. Quick responses: we have a complete service network, services for 24hours and assist you to solve the problem in a short time.
5. Parts supply: we have a complete parts supply network and can guarantee sufficient parts reserves and timely supply

power&application

A. Electric Powered / AC powered
When the electricity is available, usually for Indoor use
No noise and air pollution
Voltage: 110V, 220V, 380V, 415V

B. Diesel Powered
When the electricity is not available, usually for Outdoor use
Longer use time

C. Battery Powered / DC powered
When the electricity is not available, usually for Outdoor use
No noise and air pollution

Maintenance Schedule

A. Daily or refueling: Check the parts are good or bad Check hydraulic oil level and colour
B. Every 250hours or 3months: Change lubricating oil Check cylinders
C. Every 500hours or 6 months: Check tubes, pipes and value
D. Every 1000 hours or 1 year: Change hydraulic oil Grease rotation bearing and wear pads
E. Every 2000 hours or 2 years:Check hydraulic tank, lid and vent
F. Note: Maintain the chassis according to the Chassis’ Service manual
