Big capacity warehouse cargo lift with CE
Hydraulic warehouse cargo lift provides fast, efficient, convenient and safe access to mezzanines, balconies, basements, and any levels in multistoried building. It can be installed indoor and outdoor applications.
Model list of Hydraulic warehouse cargo elevator
Model | Load | Platform size | Lifting height | Pit depth | Dimension |
LRL 3-2.4 | 3T | 2.0*2.0M | 2.4M | 300 MM | 2.0*2.0*0.63M |
LRL 2-5 | 2T | 2.1*1.2M | 5.0M | 200 MM | 2.1*1.2*0.87M |
LRL 1-4.5 | 1T | 2.1*1.5M | 4.5M | 200 MM | 2.1*1.5*0.80M |
LRL 5-6.5 | 5T | 2.2*1.6M | 6.5M | 300 MM | 2.2*1.6*1.28M |
LRL 3-6.5 | 3T | 2.2*1.9M | 6.5M | 300 MM | 2.2*1.9*1.52M |
Outdoor Two-post lead rail lift:
We can customize the lift according to your load capacity, size of platform and lifting height; just let us know your requirements.
3. Safety control of Hydraulic warehouse cargo elevator
warehouse chain rail hydraulic lift not only have all safety device of the traditional elevator, but also have the special safety system hereinafter.
1. Spillover valve, it can prevent high pressure when the machine moves up.
2. Manual emergency valve, it can go down to the nearest floor and open the door when you meet an emergency.
3. Manual pump: it can move up the nearest floor and open the door when you meet an emergency.
4. Pipe fracture valve, when the hydraulic system pipe fracture, it can cut down the channel of the oil to stop the falling.
5. Overload protection, when the goods on the platform is over the capacity, the overload protect device will work to stop the platform lifting up.
Project case
Team&Clients:
Certification&Trade assurance:
Hot sell products:
FAQ:
Delivery Time? (From 1 week to 1 month after we receive the order)
Payments? (T/T and L/C, other kinds, pls contact with us)
MOQ? (1 set)
Trade term? (FOB/CIF to your nearest seaport)
Application field? (Construction, shipyard, industrial, airport, municipal garden or others)
A. Daily or refueling: Check the parts are good or bad Check hydraulic oil level and colour
B. Every 250hours or 3months: Change lubricating oil Check cylinders
C. Every 500hours or 6 months: Check tubes, pipes and value
D. Every 1000 hours or 1 year: Change hydraulic oil Grease rotation bearing and wear pads
E. Every 2000 hours or 2 years:Check hydraulic tank, lid and vent
F. Note: Maintain the chassis according to the Chassis’ Service manual
